3M Products & Supplies

3M™ Heat Shrink Thin-Wall Tubing FP-301-1/4-48"-Black-Hdr-12 Pcs, 48 in Length sticks with header label, 12 pieces/case - 7000133551

Sold As: 12-Pack
SKU: 7000133551
MPN: 7000133551
Stock Item: Stock items typically ship within 2-3 business days
UPC: 00051128596548
3M ID: 80611473150
5 Digit UPC: 59654
$50.12 ($4.18 / Count)
Hurry up! Current stock:

Product Description

3M™ Heat Shrink Tubing FP-301 is a general purpose, thin wall tubing that provides a balance of electrical, physical and chemical properties, making it ideal for industrial and military applications. This tubing has a 2:1 shrink ratio and provides flame retardant insulation for 600V rated applications. It has a flexible polyolefin construction that offers moisture seal protection.

Features

  • HIGH-STRENGTH PROTECTION: Balances electrical, physical, and chemical properties for various industrial and military applications
  • KEY SPECIFICATIONS: UL Listed, File E-39100, SAE AS23053/5, Class 1 (all colors), Class 2 (clear), CSA Certified, and RoHS 2011/65/EU Compliant
  • FLAME-RETARDANT TUBING: For applications up to 600V (clear is not flame retardant)
  • FOR DEMANDING CONDITIONS: Performs at an operating temperature up to 275 °F (135 °C)
  • A VARIETY OF APPLICATIONS: Offers a 2:1 shrink-fit ratio and serves as protection in wire-harnessing, split-resistance covering, wire marking, wire bundling, and component packaging
Spec Sheet



Downloads

Specifications

Shelf Life3600
Country of OriginUnited States
Inner Diameter Before Shrink (Metric)6.35
Operating Temperature (Fahrenheit)-67 °F to 275 °F
Minimum Expanded Tubing I. D.0.25
Inner Diameter After Shrink (Metric) UOMmm
Maximum Operating Temperature (Fahrenheit)275.0
Inner Diameter Before Shrink (Metric) UOMmm
Overall Width (Imperial)0.25
Overall Width (Metric)6.35
Overall Length (Imperial)48.0
Minimum Expanded Tubing I. D. UOMin
Operating Temperature Range (Celsius)-55 °C to +135 °C
Inner Diameter Before Shrink (Imperial)0.25
Inner Diameter Before Shrink (Imperial) UOMin
Operating Temperature (Celsius)-55 to 135 Degrees Celsius
Inner Diameter After Shrink (Imperial) UOMin
UL Bug Temperature (Fahrenheit)257 Degrees Fahrenheit
UL Bug Voltage600 Volt
ApplicationElectrical Insulation; High-tenacity and chemically resistant tubing
Overall Length (Metric)1220.0
Maximum Operating Temperature (Celsius)135.0
Overall Length (Imperial) UOMin
Minimum Shrink Temperature (Celsius)100.0
Maximum Operating Temperature (Fahrenheit) UOMDegree
Product ColorBlack
Maximum Operating Temperature (Celsius) UomDegree
Inner Diameter After Shrink (Imperial)0.125
Flame RetardantYes
Non-CorrosiveYes
Adhesive MaterialNone
Units per Case12.0
Tubing TypeSingle Wall (Thin)
Heat Shrink TypeSingle-Wall Polyolefin Heat Shrink Tubing
Overall Width (Metric) UOMmm
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Operating Temperature Range (Fahrenheit)-67 °F to 275 °F
Overall Length (Metric) UOMmm
Mil SpecSAE-AMS-DTL-23053/5, Class 1
Elongation UOM%
UL Bug Temperature (Celsius)125 Degrees Celsius
UL File NumberE-39100
UL ApprovalYes
MaterialPolyolefin
Shrink Ratio2:1
Overall Width (Imperial) UOMin
Inner Diameter After Shrink (Metric)3.75
