3M Products & Supplies

3M™ Adhesive Transfer Tape 9472LE, Clear, 54 in x 180 yd, 5.2 mil, 1 Roll/Case - 7000124310

SKU: 7000124310
MPN: 7000124310
For an accurate lead time please contact us
UPC: 00051115256448
3M ID: 70006430196
5 Digit UPC: 25644
$5,107.45 each
Hurry up! Current stock:

Product Description

3M™ Adhesive Transfer Tape 9472LE is a versatile, market proven, 5 mil (0.13 mm) transfer tape on a printed release liner. Featuring 3M™ 300LSE acrylic adhesive, this tape has a long and proven history of reliably bonding a wide variety of similar and dissimilar materials such as metals, most plastics, glass, papers and painted surfaces.

Features

  • Ideal solution for general purpose attachment and assemblies of a wide variety of materials
  • Excellent bond to low surface energy substrates including powder coatings and plastics such as polypropylene (PP)v
  • High adhesion to metals and high surface energy materials, making it suitable for bonding dissimilar substrates
  • Meets a wide variety of automotive and OEM specifications
  • Good resistance to industrial chemicals, consumer chemicals, moisture and humidity
  • Adhesive provides excellent holding power and anti-lifting properties
Spec Sheet



Downloads

Specifications

Shelf Life730
Country of OriginUnited States
Primary Liner Thickness (Metric) UOMmm
Overall Length (Imperial) UOMyd
Primary Liner ColorTan
Minimum Operating Temperature (Fahrenheit)-40.0
Units per Case UOMRoll
Total Tape Thickness without Liner (Metric) UOMmm
Maximum Operating Temperature (Celsius)149.0
Primary Liner Thickness (Metric)0.11
Primary Liner Thickness (Imperial) UOMmil
Primary Liner Thickness (Imperial)4.2
Overall Length (Metric)164.59
Shelf Life UOMMonth
Indoor/OutdoorIndoor/Outdoor
Product ColorTransparent
Maximum Operating Temperature (Fahrenheit) UOMDegree
Overall Length (Metric) UOMm
Specifications MetUL 969
Adhesive TypeLow Surface Energy Acrylic Adhesive 300LSE
Total Tape Thickness without Liner (Imperial)5.2
Number of Adhesive SidesDouble-sided
Units per Case1.0
Minimum Operating Temperature (Celsius) UOMDegree
Overall Width (Imperial)54.0
Minimum Operating Temperature (Fahrenheit) UOMDegree
Maximum Operating Temperature (Fahrenheit)300.0
ApplicationBonding; Commerical Signs; Emblem Attachment; Gasket Assembly; Interior Gasket & Seal Attachment; Large Surface Lamination Assembly; Mounting & Trim Attachment; Trim & Molding Attachment
Overall Length (Imperial)180.0
IndustriesAppliance, Automotive, Converter Solutions, Electronics, Furniture, General Industrial, Marine, Point of Purchase, Signage, Specialty Vehicles, Transportation, Woodworking
Overall Width (Metric)1371.6
Total Tape Thickness without Liner (Imperial) UOMmil
Overall Width (Metric) UOMmm
Total Tape Thickness without Liner (Metric)0.132
Primary Liner58# Polycoated Kraft Paper
Overall Width (Imperial) UOMin
Maximum Operating Temperature (Celsius) UOMDegree
Minimum Operating Temperature (Celsius)-40.0
