3M Products & Supplies

3M™ Block Fork Terminal Nylon with Insulation Grip Butted Seam 16-14 AWG, 95362, BS-32-10-NB, suitable for use in a terminal block - 7100171763

Sold As: 10-Pack
SKU: 7100171763
MPN: 7100171763
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00054007953623
3M ID: 80611255920
MPN: BS-32-10-NB
$245.06 ($24.51 / Count)
Hurry up! Current stock:

Product Description

Downloads

Specifications

Fork TypeBlock
Maximum Operating Temperature (Fahrenheit)221.0
Terminal StyleBlock
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Insulation MaterialNylon with Insulation Grip
Maximum Conductor Size (Imperial)14 AWG
Maximum Operating Temperature (Celsius) UOMDegree
Minimum Conductor Size (Imperial)16 AWG
Maximum Conductor Size (Metric)2.08 mm²
Country of OriginUnited States
Terminal TypeFork
Maximum Operating Temperature (Fahrenheit) UOMDegree
Barrel StyleButted
Minimum Conductor Size (Metric)1.31 mm²
Maximum Operating Temperature (Celsius)105.0
