3M Products & Supplies

3M™ Circuit Plating Tape 1280 Red, 3/4 in x 72 yd 4.2 mil, 48 per case Bulk - 7000057483

Sold As: 48-Pack
SKU: 7000057483
MPN: 7000057483
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00021200112805
3M ID: 80008002356
5 Digit UPC: 11280
$1,036.72 ($21.60 / Count)
Hurry up! Current stock:

Product Description

3M™ Circuit Plating Tape 1280 with polyester film used for PCB masking tape or other high temperature applications. Red. 3.6 mil thick.

Features

  • Polyethylene tape core instead of cardboard
  • Polyester backing reduces stretch and recovery of tape and associated uneven stop-off line
  • Thick adhesive coating reduces undercutting because adhesive helps block out solutions between fingers
  • Solvent clean up of the board is recommended to facilitate subsequent soldering
  • Low stretch polyester film for machine, as well as hand application
Spec Sheet



Downloads

Specifications

Country of OriginMexico
Overall Length (Metric) UOMm
Overall Width (Imperial) UOMin
Total Tape Thickness without Liner (Metric)0.091
Total Tape Thickness without Liner (Imperial) UOMmil
Adhesive TypeSilicone
Product ColorRed
Total Tape Thickness without Liner (Metric) UOMmm
Backing (Carrier) MaterialPolyester
Overall Length (Metric)65.837
Overall Width (Imperial)0.75
Total Tape Thickness without Liner (Imperial)3.6
Overall Length (Imperial)72.0
Overall Length (Imperial) UOMyd
Overall Width (Metric) UOMmm
Maximum Operating Temperature (Fahrenheit)311.0 Degree Fahrenheit
Maximum Operating Temperature (Celsius)155.0 Degree Celsius
