3M Products & Supplies

3Mâ„¢ Circuit Plating Tape 1280 Red, 5/8 in x 168 yds x 4.2 mil, 60/Case

Sold As: 60-Pack
SKU: 7010048800
MPN: 7010048800
Made to Order: Lead time from 3M is approximately 10 working days.
UPC: 00051115530111
3M ID: 70006461084
5 Digit UPC: 53011
Shelf Life: 548 Days
Country of Origin: Mexico
Manufacturer: 3M
Size: 0.625 in
Color: Red
$2,113.41 ($35.22 / Count)
Hurry up! Current stock:
3M Circuit Plating Tape 1280 with polyester film used for PCB masking tape or other high temperature applications. Red. 3.6 mil thick."Halogen Free" refers to the International Electrochemical Commission’s Definition, IEC 61249-2-21, which sets the limits of: 900 ppm maximum chlorine; 900 ppm maximum bromine; 1500 ppm maximum total halogens

Extra Details

  • Low stretch polyester film for machine, as well as hand application
  • Polyester backing reduces stretch and recovery of tape and associated uneven stop-off line
  • Polyethylene tape core instead of cardboard
  • Solvent clean up of the board is recommended to facilitate subsequent soldering
  • Thick adhesive coating reduces undercutting because adhesive helps block out solutions between fingers

Data Sheet

  1. Tech Data Sheet
