3M Products & Supplies

3M™ Cubitron™ ll Cloth Belt 784F, 36+ YF-weight, 5 in x 126 in, Film-lok, Special Full-flex, 25 ea/Case - 7100222758

Sold As: 25-Pack
SKU: 7100222758
MPN: 7100222758
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00638060773369
3M ID: 60440402950
5 Digit UPC: 77336
$1,257.97 ($50.32 / Count)
Hurry up! Current stock:

Product Description

3M™ Cubitron™ II Cloth Belt 784F features 3M Precision-Shaped Grain for longer life and a faster, more consistent cut than conventional ceramic aluminum oxide belts. A precise mix of shaped ceramic and premium aluminum oxide delivers optimal cut in medium-pressure grinding and blending applications. The belt also features a waterproof backing and grinding aid.

Features

  • Moderately flexible backing provides conformability for grinding and blending both straight and contoured surfaces
  • Reduces changeouts and downtime in robotic and pressure-assisted applications
  • YF-weight polyester backing is used for Grades 36-80, while lighter XF-weight polyester backing is used for Grades 120-180
  • Grinding aid cools abrasive processes on heat-sensitive alloys
  • 3M Precision-Shaped Grain blend provides significantly longer life than comparable aluminum oxide belts
  • Proprietary mineral provides consistent, faster results on medium pressure applications, helping to improve productivity and throughput
Spec Sheet



Downloads

Specifications

Country of OriginUnited States
Overall Length (Imperial)126.0
Mesh Size0.0
Backing WeightYF Weight
ApplicationDeburring; Finishing; Grinding; Polishing
Overall Width (Metric)3200.0
Wet or DryWet or Dry
Number of Vacuum Holes-12345.0
Product CategoryCoated Abrasives
Product FormBelt
Overall Length (Imperial) UOMin
Overall Width (Imperial)5.0
Grit36+
Splice TypeFilm-lok
Coat TypeClosed Coat
Overall Length (Metric) UOMmm
Overall Width (Imperial) UOMin
Abrasive MaterialPrecision Shaped Ceramic
Overall Length (Metric)3200.4
Backing MaterialPolyester Cloth
Sub ApplicationsWeld Grinding
Overall Width (Metric) UOMmm
Flex TypeFull-flex
Product ColorMaroon
