3M™ Cushion-Mount™ Plus Plate Mounting Tape E1515H, Purple, 18 in x 25 yd, 15 mil, 1 roll per case - 7000047431

SKU: 7000047431
MPN: 7000047431
For an accurate lead time please contact us
UPC: 051125748353
3M ID: 70002020231
5 Digit UPC: 74835
$631.24 each
Hurry up! Current stock:

Product Description

Our 3M™ Cushion-Mount™ Plus Plate Mounting Tape E1515H with easy mount adhesive is designed for mounting flexographic print plates to cylinders or sleeves. This 0.015 inch (0.38 mm) purple foam mounting tape provides high quality medium combination print.

Features

  • Cross-hatch pattern in release liner creates grooves in adhesive to help release air
  • Cushioned flexographic plate mounting sticky back foam tape
  • Plate demounts from the tape without adhesive residue
  • Purple foam color indicates medium density foam
  • Securely bonds flexographic photopolymer plates to print sleeves or steel cylinders to prevent plate edge lifting
  • Air release feature helps eliminate air bubbles under plates
  • Tape removes cleanly from sleeves or steel print cylinders
  • Higher plate side adhesion meets challenging print conditions using thick plates or small print sleeves
  • For flexographic printing, flexographic printers
  • Plate side adhesive technology is designed to resist edge lifting on flexographic print plates
  • Medium density foam is ideal for combinations of solids and process with halftone dots

Downloads

Specifications

Urethane SleevesYes
Air ReleaseYes
Warranty Period2 Years from Date of Manufacture
Primary Liner Thickness (Metric)0.11 mm
ApplicationFlexographic Plate Mounting
Composite SleevesYes
Color FamilyPurple
Product NumberE1515H
Total Tape Thickness without Liner (Metric)0.43 mm
Total Tape Thickness without Liner (Imperial)17 mil
Backing Thickness (Metric)0.432 mm
Application Thickness (Imperial)15 mil
Product FormRoll
Overall Length (Imperial)25 yd
Primary LinerPolycoated Polyester
Overall Width (Metric)457.2 mm
Primary Liner Thickness (Imperial)4.5 mil
Backing MaterialPolyethylene Foam
Application Thickness (Metric)0.4 mm
Product ColorPurple
Print QualityCombination Printing - Medium
Print Quality (Series)15 Series
Overall Width (Imperial)18 in
Adhesive TypeDifferential Acrylate
