3M Products & Supplies

3M™ Diamond Lapping Film 662XW, 1.0 Micron Roll, 1 in x 50 ft x 1 in ASO, 1/Case - 7010298844

SKU: 7010298844
MPN: 7010298844
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051111698105
3M ID: 60020010470
5 Digit UPC: 69810
$528.25 each
Hurry up! Current stock:

Product Description

3M™ Diamond Lapping Film 662XW has a higher diamond concentration and a stronger resin bond to give this product added durability and increased cut rate over our standard diamond lapping film. Available in 0.50, 1.0, 1.50, 3.0, 6.0 and 9.0 micron grades.

Features

  • Available in discs, rolls and sheets
  • Good finish
  • Flat surface, no rounding
  • A higher diamond concentration and a stronger resin bond give this product added durability and increased cut rate over our standard diamond lapping film
  • Increased throughput
  • Long abrasive life minimizes disc changes
Spec Sheet



Downloads

Specifications

Country of OriginUnited States
Product UsageFiber Optic Connectors
Overall Length (Imperial) UOMft
Overall Diameter (Metric)0.0
Overall Length (Metric)15.24
Center Hole Diameter (Imperial)0.0
Backing Thickness (Imperial)3.0
Product FormRoll
Center Hole Diameter (Metric)0.0
ApplicationFlat Lapping; Polishing; Superfinishing
Micron Grade1 μm
Overall Diameter (Imperial)0.0
Product ColorLavender
Abrasive MaterialDiamond
Overall Width (Metric)25.4
Attachment TypePlain Back
SubstrateCarbide; Ceramic; Composite; Exotic Alloy; Glass; Hardened Metal; Quartz; Sapphire; Stone
Backing Thickness (Metric)0.076
Product Series662XW
Overall Width (Metric) UOMmm
Backing Thickness (Metric) UOMmm
Overall Length (Imperial)50.0
Overall Width (Imperial)1.0
Overall Length (Metric) UOMm
Backing Thickness (Imperial) UOMmil
Overall Width (Imperial) UOMin
Backing MaterialPolyester Film
