3M Products & Supplies

3M™ Diamond Lapping Film 663X, 30.0 Micron Sheet, 9 in x 11 in, 10/Inner, 100/Case - 7010298847

Sold As: 10-Pack
SKU: 7010298847
MPN: 7010298847
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051111699867
3M ID: 60020012237
5 Digit UPC: 69986
$480.58 ($48.06 / Count)
Hurry up! Current stock:

Product Description

3M™ Diamond Lapping Film 663X has a stronger resin system that gives this product added toughness and longer life. Used primarily in superfinishing, roll polishing, and flat lapping applications. Available in 30.0, 45.0, and 60.0 micron grades.

Features

  • Fast cut
  • Increased durability
  • Available in rolls, discs and sheets
  • Uniform finish
  • Flat surface, low rounding
  • Long abrasive life minimizes abrasive changes
Spec Sheet



Downloads

Specifications

Country of OriginUnited States
Overall Width (Metric)228.6
Center Hole Diameter (Imperial)0.0
Center Hole Diameter (Metric)0.0
Product UsageFiber Optic Connectors
Attachment TypePlain Back
Overall Width (Imperial)9.0
Product Series663X
SubstrateCarbide; Ceramic; Composite; Exotic Alloy; Glass; Hardened Metal; Stone
Abrasive MaterialDiamond
Overall Length (Metric) UOMmm
Overall Length (Imperial)11.0
Overall Width (Imperial) UOMin
Backing Thickness (Metric) UOMmm
Overall Length (Metric)279.4
Product ColorGreen
Backing Thickness (Imperial)3.0
Overall Width (Metric) UOMmm
Backing Thickness (Imperial) UOMmil
Micron Grade30 μm
Product FormSheet
Overall Diameter (Imperial)0.0
ApplicationFlat Lapping; Polishing; Superfinishing
Overall Diameter (Metric)0.0
Backing Thickness (Metric)0.076
Overall Length (Imperial) UOMin
Backing MaterialPolyester Film
