3M Products & Supplies

3M™ Double Coated Tape 415, Clear, 27 in x 36 yd, 4 mil, 1 Roll/Case - 7100009839

SKU: 7100009839
MPN: 7100009839
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00021200670961
3M ID: 70006087475
5 Digit UPC: 67096
$907.37 each
Hurry up! Current stock:

Product Description

3M™ Double Coated Tape 415 is a double coated tape that offers a balance of high initial adhesion and good holding power on a variety of substrates, especially paper. Double sided adhesion increases dimensional stability for easy handling, making it an ideal choice for both zero speed and flying splices during printing.

Features

  • Double sided adhesion increases dimensional stability for easy handling during print splicing
  • Ideal for printing applications, with high tack and adhesion to most paper stocks
  • Good adhesion to a variety of substrates, including low and high surface energy substrates
  • Excellent UV, moderate temperature and good humidity resistance to ensure performance in a variety of situations
  • Densified kraft paper liner ensures easy handling
Spec Sheet



Downloads

Specifications

Shelf Life730
Country of OriginUnited States
Backing (Carrier) Thickness (Imperial)1.0
Primary Liner60# Densified Kraft Paper
Maximum Operating Temperature (Celsius)82.0
Minimum Operating Temperature (Celsius) UOMDegree
Backing (Carrier) MaterialPET
Overall Width (Metric)685.8
Total Tape Thickness without Liner (Imperial)3.9
Indoor/OutdoorIndoor/Outdoor
IndustriesAppliance, Consumer Goods, Converter Solutions, Craft, Electronics, Food and Beverage, General Industrial, MRO, Packaging, Paper, Point of Purchase, Print, Signage
Minimum Operating Temperature (Celsius)-40.0
Back Side Adhesive Thickness (Imperial) UOMmil
Total Tape Thickness without Liner (Imperial) UOMmil
Overall Width (Metric) UOMmm
Primary Liner Thickness (Imperial) UOMmil
Overall Width (Imperial) UOMin
Primary Liner Thickness (Imperial)3.5
Adhesive TypeHigh Tack Acrylic 400
Overall Length (Imperial) UOMyd
Backing (Carrier) Thickness (Imperial) UOMmil
Minimum Operating Temperature (Fahrenheit)-40.0
Primary Liner Thickness (Metric)0.089
Shelf Life UOMMonth
Units per Case1.0
Face Side Adhesive Thickness (Metric)0.038
Number of Adhesive SidesDouble-sided
ApplicationAttaching; Bonding; High Tack Adhesion; Holding; Joining; Laminating; Mounting; Splicing
Face Side Adhesive Thickness (Imperial) UOMmil
Maximum Operating Temperature (Fahrenheit)180.0
Primary Liner Thickness (Metric) UOMmm
Total Tape Thickness without Liner (Metric)0.1
Maximum Operating Temperature (Celsius) UOMDegree
Product ColorTransparent
Maximum Operating Temperature (Fahrenheit) UOMDegree
Face Side Adhesive Thickness (Metric) UOMmm
Overall Width (Imperial)27.0
Overall Length (Metric) UOMm
Primary Liner ColorTan
Backing (Carrier) Thickness (Metric) UOMmm
Minimum Operating Temperature (Fahrenheit) UOMDegree
Overall Length (Metric)32.91
Overall Length (Imperial)36.0
Total Tape Thickness without Liner (Metric) UOMmm
Back Side Adhesive Thickness (Imperial)1.5
Face Side Adhesive Thickness (Imperial)1.5
Backing (Carrier) Thickness (Metric)0.025
