3M Products & Supplies

3M™ Double Coated Tape 9019, Clear, 54 in x 60 yd, 1.1 mil, 1 Roll/Case - 7000017157

SKU: 7000017157
MPN: 7000017157
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00048011583419
3M ID: 70006405156
5 Digit UPC: 58341
$1,391.41 each
Hurry up! Current stock:

Product Description

3M™ Double Coated Tape 9019 is .3 mils of 300 high strength acrylic adhesive, .5 mil polyester carrier, .3 mils of 300 high strength acrylic adhesive on a 3.2 mil 55 lb densified kraft paper liner

Features

  • Film carrier makes for easy handling during slitting and die-cutting
  • 1.1 mil double coated tape with a PET polyester carrier on a 55 lb densified kraft paper liner DK
  • Good for joining and bonding in electronics and general industrial applications. Foam and gasket attachment
  • High bonding strength to LSE plastics
  • Film carrier adding dimensional stability to foams and other substrates
  • High adhesion to a wide variety of materials such as HSE LSE and metals. Good temperature resistance and good UV resistance. Good peel strength
Spec Sheet



Downloads

Specifications

Shelf Life730
Country of OriginUnited States
Indoor/OutdoorIndoor/Outdoor
Maximum Operating Temperature (Celsius) UOMDegree
Maximum Operating Temperature (Fahrenheit)250.0
Maximum Operating Temperature (Celsius)121.0
Primary Liner Thickness (Imperial)3.0
Total Tape Thickness without Liner (Metric) UOMmm
ApplicationBonding
Overall Length (Imperial)60.0
Back Side Adhesive Thickness (Imperial)0.3
Face Side Adhesive Thickness (Imperial)0.3
Minimum Operating Temperature (Fahrenheit) UOMDegree
Face Side Adhesive Thickness (Metric) UOMmm
Primary Liner Thickness (Imperial) UOMmil
IndustriesElectronics, General Industrial
Units per Case1.0
Backing (Carrier) Thickness (Imperial) UOMmil
Backing (Carrier) MaterialPET
Overall Width (Imperial) UOMin
Primary Liner55# Densified Kraft Paper (DK)
Overall Width (Imperial)54.0
Total Tape Thickness without Liner (Imperial) UOMmil
Shelf Life UOMMonth
Product ColorTransparent
Primary Liner ColorWhite
Backing (Carrier) Thickness (Metric) UOMmm
Face Side Adhesive Thickness (Imperial) UOMmil
Total Tape Thickness without Liner (Metric)0.028
Face Side Adhesive Thickness (Metric)0.0084
Primary Liner Thickness (Metric)0.076
Overall Width (Metric) UOMmm
Maximum Operating Temperature (Fahrenheit) UOMDegree
Adhesive TypeHigh Performance Adhesive 300
Total Tape Thickness without Liner (Imperial)1.1
Back Side Adhesive Thickness (Imperial) UOMmil
Product CategoryAdhesive Transfer Tapes & Double Coated Tapes
Primary Liner Thickness (Metric) UOMmm
Backing (Carrier) Thickness (Metric)0.013
Back Side Adhesive Thickness (Metric)0.0084
Overall Length (Metric) UOMm
Minimum Operating Temperature (Celsius)-40.0
Overall Length (Imperial) UOMyd
Overall Width (Metric)1371.6
Backing (Carrier) Thickness (Imperial)0.5
Minimum Operating Temperature (Fahrenheit)-40.0
Back Side Adhesive Thickness (Metric) UOMmm
Overall Length (Metric)54.86
Minimum Operating Temperature (Celsius) UOMDegree
