3M Products & Supplies

3M Epoxy Film Electrical Tape Super 20-1"X60YDS, White, Acrylic Adhesive, 1 in x 60 yd (25,40 mm x 55 m), 36 per case

Sold As: 36-Pack
SKU: 7000149351
MPN: 20-1"X60YDS
Lead Time: 24 working days.
UPC: 00051138691769
3M ID: 80610945059
5 Digit UPC: 69176
$4,697.16 ($130.48 / Count)
Hurry up! Current stock:

Product Description

Overview

  • 3M™ Epoxy Film Electrical Tape Super 20 is a 5-mil thick, high dielectric electrical tape. This flame-retardant tape is used as a coil cover, anchor, harnessing, banding, core, layer and crossover insulation. This tape is 600V-rated and withstands a temperature range of 32 to 311 degrees F (0 to 155 degrees C).
  • The combination of the acrylic adhesive and the epoxy film backing provides excellent adherence and electrical properties
  • 3M™ Tape Super 20 has an acrylic, pressure-sensitive adhesive and is resistant to heat, oxidation, solvents and oils. This puncture-resistant tape has excellent electrical and handling properties. Highly conformable tape is tough and provides resistant to solder damage. It is suitable for use in wrapping relays, coils, transformers, bobbin-wound sub-fractional horsepower shaded-pole motors and stick-wound coils. UL Listed and RoHS 2011/65/EU Compliant.
  • UL Listed and RoHS 2011/65/EU Compliant
  • Flame-retardant and highly resistant to heat, oxidation, solvents and oils
  • Suitable for use in transformers, coils, stick-wound coils, wrapping relays and bobbin-wound, sub-fractional horsepower, shaded-pole motors
  • Printable
  • Withstands a temperature range of 32 to 311 degrees F (0 to 155 degrees C)

Legal Disclaimer

  • Manufacturing Origin: USA
  • The designation that a product is Manufactured in the USA means the product undergoes substantial transformation in one of our U.S. Manufacturing plants. Some products contain imported components.
  • Note: 3M products offered on a government contract that require country of origin representation must be certified by 3M Trade Compliance. Contact customer service at 800-245-3573 to request a certificate.
Spec Sheet



Specifications

ColorCream
Elongation at Break120%
Backing Thickness (metric)3.5 mm
Product TypeEpoxy Film Tape
Flame ResistantYes
Width1 Inch
Product MarketsElectrical Equipment Manufacturing
Tape TypeElectrical Insulating Tapes for Equipment Manufacturing
Breaking Strength45 lb/in
Backing MaterialEpoxy Film
Length (Metric)55 m
Maximum Operating Temperature (Celsius)155 Degree Celsius
Thickness5 mil
Length60 Linear Yard
UL 510Yes
Dielectric Breakdown8000 Volt
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
RoHS 2011/65/EU CompliantYes
Insulation Resistance1 x 10^6 megohms
Adhesive MaterialAcrylic
Thickness (Metric)5 mm
Printed TapeYes
Operating Temperature (Celsius)155°
Agency ApprovalsCSA Certified, Flame Retardant, UL Recognized
Electrolytic Corrosion Factor1
Operating Temperature Range (Celsius)0 °C to 155 °C
Adhesion to Steel oz/in (N/100 mm)30 (33)
