3M Products & Supplies

3M™ Glass Cloth Tape 361, White, 1 1/2 in x 60 yd, 6.4 mil, 24 Roll/Case - 7100040610

Sold As: 24-Pack
SKU: 7100040610
MPN: 7100040610
Stock Item: Stock items typically ship within 2-3 business days
UPC: 00021200055133
3M ID: 70006038478
5 Digit UPC: 5513
$4,468.71 ($186.20 / Count)
Hurry up! Current stock:

Product Description

Constructed with a woven fiberglass backing, 3M™ Glass Cloth Tape 361 features a pressure sensitive silicone adhesive for applications requiring high-temperature resistance, high adhesion and clean removal. It is often used for high temperature applications such as sealing ducts and as a back-up strip for submerged arc welding.

Features

  • Can be certified to meet F.A.R. 25.853, flame resistant specification
  • Strong abrasion resistant backing provides strength for bundling, harnessing and protection applications requiring high tensile strength
  • Silicone adhesive provides good holding power and clean removal across a wide range of temperatures
  • Withstands temperatures from -65°F/-54°C to 450°F/232°C and intermittent temperatures up to 550°F/288°C or higher, depending on the type and duration of the heat source
  • Used for permanent sealing of high temperature ducts or chambers
Spec Sheet



Downloads

Specifications

Shelf Life730
Country of OriginUnited States
Overall Width (Imperial) UOMin
Back Side Adhesive Thickness (Metric) UOMmm
Overall Length (Metric) UOMm
Minimum Operating Temperature (Fahrenheit)-65.0
Shelf Life UOMMonth
Minimum Operating Temperature (Celsius) UOMDegree
Core Size (Imperial)3.0
Tensile Strength (Imperial) UOMoz/in
Back Side Adhesive Thickness (Metric)0.04
Total Tape Thickness without Liner (Imperial)6.4
Backing (Carrier) MaterialGlass Cloth
Core Size (Metric)7.62
Maximum Operating Temperature (Fahrenheit) UOMDegree
Specifications MetASTM D3330, ASTM D3758, D3652, F.A.R. 25.853(a)
Tensile Strength (Metric) UOMN/100mm
Core Size (Metric) UOMcm
Overall Width (Metric)3.8
ApplicationSurface Protection
Backing (Carrier) Thickness (Metric) UOMmm
Maximum Operating Temperature (Celsius)232.0
Core Size (Imperial) UOMin
Backing (Carrier) Thickness (Imperial) UOMmil
Maximum Operating Temperature (Fahrenheit)450.0
Total Tape Thickness without Liner (Imperial) UOMmil
Backing (Carrier) Thickness (Imperial)5.0
Total Tape Thickness without Liner (Metric)0.16
Indoor/OutdoorIndoor/Outdoor
Overall Length (Imperial)60.0
Minimum Operating Temperature (Fahrenheit) UOMDegree
Overall Length (Imperial) UOMyd
Overall Length (Metric)54.9
Units per Case24.0
Overall Width (Metric) UOMcm
Total Tape Thickness without Liner (Metric) UOMmm
Overall Width (Imperial)1.5
IndustriesAerospace, Automotive, Construction, General Industrial, Military and Government, Specialty Vehicles, Transportation
Backing (Carrier) Thickness (Metric)0.13
Minimum Operating Temperature (Celsius)-54.0
Product ColorWhite
Adhesive TypeSilicone
Back Side Adhesive Thickness (Imperial)1.4
Back Side Adhesive Thickness (Imperial) UOMmil
Elongation at Break9
Tensile Strength (Metric)38.0
Tensile Strength (Imperial)2336.0
Maximum Operating Temperature (Celsius) UOMDegree
