3M Products & Supplies

3M™ H/D Vinyl Insulated Butted Seam Ring Tongue Terminal 123-10-P, 1000/case, Max. Temp. 347 °F (175 °C) for bare terminals - 7100163743

Sold As: 1000-Pack
SKU: 7100163743
MPN: 7100163743
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00054007289197
3M ID: 80601386362
MPN: 123-10-P
$241.19 ($0.24 / Count)
Hurry up! Current stock:

Product Description

This terminal has a wire range of 8 AWG and a stud size of 1/4. It comes in quantities of 25 per carton and 250 per case.

Features

  • 600V-rated for building wire and 1000V for signs, fixtures or luminaires
  • Standard-style ring tongue fits around the stud
  • Made of electrolytic copper for good conductivity and has tin plating for corrosion resistance
  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
  • Funnel-designed, seamless brass sleeve offers easy insertion of wires
  • Nylon-insulated, butted-seam barrel ensures a secure fit and offers reliable performance

Downloads

Specifications

Minimum Stud Diameter (Metric)5.0
UL File NumberE23438
Maximum Operating Temperature (Celsius)175.0
Ring TypeStandard
Minimum Conductor Size (Metric)1.31 mm²
Minimum Stud Diameter (Metric) UOMmm
Barrel Length (Imperial)0.25 Inch
Connection TypeCrimp
Country of OriginUnited States
Terminal TypeRing
Maximum Conductor Size (Imperial)12 AWG
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Insulation MaterialVinyl
Minimum Stud Diameter (Imperial) UOMin
Maximum Conductor Size (Metric)3.31
Minimum Conductor Size (Imperial)16 AWG
Maximum Operating Temperature (Celsius) UOMDegree
Barrel StyleBrazed
Terminal StyleStandard
