3M Products & Supplies

3M™ High Temperature Butted Seam Butt Connector HT-63, withstands a maximum temperature of 900 degrees f (482 degrees c) - 7000148825

Sold As: 1000-Pack
SKU: 7000148825
MPN: 7000148825
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 50054007293687
3M ID: 80601390901
MPN: HT-63
$129.66 ($0.13 / Count)
Hurry up! Current stock:

Product Description

This terminal has a wire range of 16-14 AWG and case quantities of 500 per case.

Features

  • 600V-rated for building wire and 1000V for signs, fixtures or luminaires
  • RoHS 2011/65/EU Compliant
  • Built-in wire stop for correct positioning
  • Made of nickel-plated, annealed steel
  • Maximum Temperature Range of 900 degrees F (482 degrees C)

Downloads

Specifications

Body MaterialStainless Steel
Minimum Conductor Size (Imperial)12 AWG
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Connector TypeButt
Minimum Conductor Size (Metric)4 mm²
Insulation MaterialNon-insulated
Country of OriginUnited States
Maximum Conductor Size (Imperial)10 AWG
Maximum Conductor Size (Metric)6 mm²
Maximum Insulation Outer Diameter (Metric)0.0
Connection Width (Metric)0.0
Terminal TypeButt Connectors
Connection Width (Imperial)0.0
