3M Products & Supplies

3M™ High Temperature Non-Insulated Butted Seam Female Disconnect, HT-72F-187-20, Max. Temp. 900 °F (482 °C) - 7100163799

Sold As: 1000-Pack
SKU: 7100163799
MPN: 7100163799
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00054007293699
3M ID: 80601390919
MPN: HT-72F-187-20
$104.86 ($0.10 / Count)
Hurry up! Current stock:

Product Description

3M™ Standard Female Disconnect Terminals have dents and rolled edges to offer great holding force while allowing for quick and easy disconnect. The terminal has a nylon-insulated, butted-seam barrel and withstands temperatures of -40 to 221 degrees F (-40 to 105 degrees C). Its durable brass construction offers good conductivity and a tin-plated finish resists corrosion.

Features

  • Allows for quick and easy disconnect of wires
  • UL Listed, CSA Certified and RoHS 2011/65/EU Compliant
  • Made of durable brass for good conductivity and has corrosion-resistant tin plating
  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
  • Rated 600V for building wire and 1000V for signs, fixtures or luminaires

Downloads

Specifications

RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Country of OriginUnited States
Disconnect TypeFemale
Maximum Conductor Size (Metric)2.5 mm²
Connection Width (Metric) UOMmm
Minimum Conductor Size (Metric)1.5 mm²
Minimum Conductor Size (Imperial)16 AWG
Connection Width (Imperial) UOMin
Maximum Conductor Size (Imperial)14 AWG
Connection Width (Imperial)0.187
Connection Width (Metric)4.75
Terminal TypeDisconnect
