3M Products & Supplies

3M™ Lapping Film 262X Type F, 1.0 Micron Sheet, 8.50 in x 11 in,25/Inner, 600/Case - 7010360265

Sold As: 600-Pack
SKU: 7010360265
MPN: 7010360265
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051111700259
3M ID: 60020012617
5 Digit UPC: 70025
$872.16 ($1.45 / Count)
Hurry up! Current stock:

Product Description

Aluminum oxide mineral coated on 3-mil polyester film with a softer resin system, in grades 1.0 and 2.0 micron. Used in polishing fiber optics as well as precision lapping operations. Provides smooth surface on precision electronic parts.

Features

  • Softer resin than other aluminum oxide products
  • Available in discs, sheets and rolls
  • Tight particle distribution
  • Consistent cut rate, finish and life
Spec Sheet



Downloads

Specifications

Country of OriginUnited States
Product FormSheet
Abrasive MaterialAluminum Oxide
Overall Length (Metric) UOMmm
Backing Thickness (Metric)0.076
Backing Thickness (Metric) UOMmm
Center Hole Diameter (Imperial)0.0
Overall Diameter (Imperial)0.0
Specifications MetRoHS 2011/65/EU
Product ColorGreen
Overall Diameter (Metric)0.0
Overall Width (Metric) UOMmm
Overall Width (Imperial)8.5
Overall Length (Metric)279.4
Overall Length (Imperial)11.0
Overall Width (Metric)215.9
Product UsageFiber Optic Connectors
Overall Length (Imperial) UOMin
ApplicationFinishing; Flat Lapping; Polishing; Superfinishing
Backing Thickness (Imperial)3.0
Backing MaterialPolyester Film
Attachment TypePlain Back
SubstrateCeramic; Glass; High-hardness Metal; Metal; Plastic; Silicon Carbide
Micron Grade1 μm
Product Series262X
Backing Thickness (Imperial) UOMmil
Center Hole Diameter (Metric)0.0
Overall Width (Imperial) UOMin
