3M Products & Supplies

3M™ Locking Fork, Vinyl Insulated Butted Seam 22-18 AWG, 94863, SS-31-10-P - 7100164990

Sold As: 10-Pack
SKU: 7100164990
MPN: 7100164990
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00054007948636
3M ID: 80611253636
MPN: 94863
$146.84 ($14.68 / Count)
Hurry up! Current stock:

Product Description

3M™ Highland™ Locking Fork Terminal has a spring-like tongue to securely lock around the stud. The terminal has a vinyl-insulated, butted-seam barrel and withstands temperatures of -40 to 221 degrees F (-40 to 105 degrees C). Electrolytic copper construction offers good conductivity and a tin-plated finish resists corrosion.

Features

  • Funnel-designed, polyvinyl chloride sleeve offers easy insertion of wires
  • Spring-like tongue firmly fits around the stud
  • Vinyl-insulated, butted-seam barrel ensures a secure fit and offers reliable performance

Downloads

Specifications

Minimum Conductor Size (Imperial)22 AWG
Maximum Conductor Size (Imperial)18 AWG
Barrel StyleButted
Terminal TypeFork
Fork TypeLocking
Country of OriginUnited States
Minimum Conductor Size (Metric)0.326 mm²
Insulation MaterialVinyl
Maximum Conductor Size (Metric).0823 mm²
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Terminal StyleLocking
