3M Products & Supplies

3M™ Membrane Switch Spacer Double Linered 9045MP, Clear, 24 in x 36 in, 5 mil, 50 Sheets/Case - 7000049681

SKU: 7000049681
MPN: 7000049681
For an accurate lead time please contact us
UPC: 00051115634710
3M ID: 70006734290
5 Digit UPC: 63471
$641.42 each
Hurry up! Current stock:

Product Description

3M™ Membrane Switch Spacer Double Linered 9045MP features 3M™ High Performance Acrylic Adhesive 200MP, formulated for excellent shear strength, on a 1 mil PET film carrier. Adhesive withstands repeated switch actuation and forms clean edges for precise slitting and die-cutting. Heavy 94# PCK paper liners resist humidity, curling, tunneling and buckling and add stability for improved processing.

Features

  • 5 mil double-coated spacer is ideal for withstanding repeated stress of switch actuation
  • Heavy 94# polycoated kraft (PCK) liners deliver improved handling and lay-flat
  • Liners add dimensional stability for high-speed rotary die-cutting
  • Adhesive resists oozing at slits and die-cuts for faster part processing
  • 1 mil polyester film carrier provides strength and stability
  • 2 mil 3M™ Acrylic Adhesive 200MP delivers excellent shear strength, resists slippage and edge lifting
Spec Sheet



Downloads

Specifications

Shelf Life730
Country of OriginUnited States
Secondary Liner Thickness (Imperial) UOMmil
Overall Length (Metric)914.4
Total Tape Thickness without Liner (Metric)0.13
Secondary Liner Thickness (Metric) UOMmm
Total Tape Thickness without Liner (Imperial)5.0
Backing (Carrier) MaterialPolyester Film
Back Side Adhesive Thickness (Imperial)2.0
Secondary Liner Thickness (Metric)0.18
Maximum Operating Temperature (Fahrenheit)400.0
Primary Liner Thickness (Imperial) UOMmil
Face Side Adhesive Thickness (Imperial) UOMmil
Minimum Operating Temperature (Fahrenheit) UOMDegree
Overall Width (Imperial)24.0
Overall Length (Imperial)36.0
Primary Liner Thickness (Metric)0.18
IndustriesAerospace, Appliance, Automotive, Converter Solutions, Electronics, General Industrial, MRO, Medical, Metalworking, Military and Government, Point of Purchase, Print, Signage, Specialty Vehicles, Transportation, Woodworking
Secondary Liner94# Polycoated Kraft Paper
Secondary Liner Thickness (Imperial)7.0
Backing (Carrier) Thickness (Metric) UOMmm
Back Side Adhesive Thickness (Metric)0.05
Primary Liner94# Polycoated Kraft Paper
Product ColorTransparent
Primary Liner ColorWhite
Total Tape Thickness without Liner (Imperial) UOMmil
Primary Liner Thickness (Metric) UOMmm
Secondary Liner ColorWhite
Units per Case50.0
Total Tape Thickness without Liner (Metric) UOMmm
Overall Length (Imperial) UOMin
Primary Liner Thickness (Imperial)7.0
Overall Width (Metric)609.6
Back Side Adhesive Thickness (Imperial) UOMmil
Back Side Adhesive Thickness (Metric) UOMmm
Face Side Adhesive Thickness (Metric) UOMmm
Backing (Carrier) Thickness (Metric)0.03
Face Side Adhesive Thickness (Metric)0.05
Adhesive TypeHigh Performance Acrylic Adhesive 200MP
Maximum Operating Temperature (Fahrenheit) UOMDegree
Minimum Operating Temperature (Fahrenheit)-40.0
Backing (Carrier) Thickness (Imperial) UOMmil
Face Side Adhesive Thickness (Imperial)2.0
Backing (Carrier) Thickness (Imperial)1.0
Overall Length (Metric) UOMmm
Shelf Life UOMMonth
Overall Width (Imperial) UOMin
Overall Width (Metric) UOMmm
