3M Products & Supplies

3M™ Non-Insulated Brazed Seam Multi-Stud Ring Tongue Terminal, 11-610-W, 1,000/case - 7100163824

Sold As: 1000-Pack
SKU: 7100163824
MPN: 7100163824
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00054007296393
3M ID: 80601394200
MPN: 11-610-W
$139.42 ($0.14 / Count)
Hurry up! Current stock:

Product Description

This terminal has a wire range of 8 AWG and a stud size of 1/4. It comes in quantities of 25 per carton and 250 per case.

Features

  • Funnel-designed, seamless brass sleeve offers easy insertion of wires
  • 600V-rated for building wire and 1000V for signs, fixtures or luminaires
  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
  • Nylon-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
  • Made of electrolytic copper for good conductivity and has tin plating for corrosion resistance
  • Standard-style ring tongue fits around the stud

Downloads

Specifications

Minimum Conductor Size (Metric)0.326 mm²
Minimum Conductor Size (Imperial)22 AWG
Connection TypeCrimp
Maximum Operating Temperature (Celsius) UOMDegree
Insulation MaterialNon-insulated
Maximum Conductor Size (Metric)0.823
Terminal StyleStandard
Minimum Stud Diameter (Metric)3.5
Minimum Stud Diameter (Metric) UOMmm
Maximum Operating Temperature (Celsius)175.0
Ring TypeStandard
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Maximum Conductor Size (Imperial)18 AWG
UL File NumberE23438
Country of OriginUnited States
Barrel Length (Imperial)0.25 Inch
Barrel StyleBrazed
Terminal TypeRing
Minimum Stud Diameter (Imperial) UOMin
