3M™ Non-Insulated Brazed Seam Ring Tongue Terminal 13-38S-W, Max. Temp. 347 °F (175 °C) for bare terminals - 7100163690

Sold As: 1000-Pack
SKU: 7100163690
MPN: 7100163690
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00054007287438
3M ID: 80601384581
MPN: 13-38S-W
$185.04 ($0.19 / Count)
Hurry up! Current stock:

Product Description

This terminal has a wire range of 8 AWG and a stud size of 1/4. It comes in quantities of 25 per carton and 250 per case.

Features

  • Standard-style ring tongue fits around the stud
  • Funnel-designed, seamless brass sleeve offers easy insertion of wires
  • Made of electrolytic copper for good conductivity and has tin plating for corrosion resistance
  • Nylon-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
  • 600V-rated for building wire and 1000V for signs, fixtures or luminaires
  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)

Downloads

Specifications

Connection TypeCrimp
Maximum Conductor Size (Metric)5.26
Minimum Conductor Size (Imperial)12 AWG
Barrel Length (Imperial)0.25 Inch
Insulation MaterialNon-insulated
Barrel StyleBrazed
Minimum Stud Diameter (Metric) UOMmm
Maximum Operating Temperature (Celsius)175.0
Minimum Stud Diameter (Metric)9.525
Terminal TypeRing
UL File NumberE23438
Country of OriginUnited States
Minimum Stud Diameter (Imperial) UOMin
Maximum Operating Temperature (Celsius) UOMDegree
Ring TypeStandard
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Minimum Conductor Size (Metric)3.31 mm²
Terminal StyleStandard
Maximum Conductor Size (Imperial)10 AWG
