3M™ Non-Insulated Brazed Seam Ring Tongue Terminal 15-56-W, Max. Temp. 347 °F (175 °C) for bare terminals - 7100163758

Sold As: 1000-Pack
SKU: 7100163758
MPN: 7100163758
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00054007291060
3M ID: 80601388244
MPN: 15-56-W
$367.90 ($0.37 / Count)
Hurry up! Current stock:

Product Description

This terminal has a wire range of 8 AWG and a stud size of 1/4. It comes in quantities of 25 per carton and 250 per case.

Features

  • Standard-style ring tongue fits around the stud
  • Made of electrolytic copper for good conductivity and has tin plating for corrosion resistance
  • Nylon-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
  • 600V-rated for building wire and 1000V for signs, fixtures or luminaires
  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
  • Funnel-designed, seamless brass sleeve offers easy insertion of wires

Downloads

Specifications

Minimum Stud Diameter (Metric) UOMmm
Connection TypeCrimp
Maximum Operating Temperature (Celsius)175.0
Minimum Stud Diameter (Imperial) UOMin
Insulation MaterialNon-insulated
Maximum Conductor Size (Imperial)6 AWG
Maximum Conductor Size (Metric)13.3
Country of OriginUnited States
Terminal TypeRing
Barrel Length (Imperial)0.25 Inch
Maximum Operating Temperature (Celsius) UOMDegree
UL File NumberE23438
Terminal StyleStandard
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Minimum Conductor Size (Imperial)6 AWG
Minimum Conductor Size (Metric)13.3 mm²
Minimum Stud Diameter (Metric)7.95
Barrel StyleBrazed
Ring TypeStandard
