3M Products & Supplies

3M™ Non-Insulated Butted Seam Hook Tongue Terminal 42-10, 1000/case - 7100163642

Sold As: 1000-Pack
SKU: 7100163642
MPN: 7100163642
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00054007286363
3M ID: 80601383468
MPN: 42-10
$92.13 ($0.09 / Count)
Hurry up! Current stock:

Product Description

3M™ Hook Terminal allows terminal to wrap around a portion of a free-standing stud for a secure and reliable connection. The terminal has a vinyl-insulated, butted-seam barrel and withstands temperatures of -40 to 221 degrees F (-40 to 105 degrees C). Electrolytic copper construction offers good conductivity and a tin-plated finish resists corrosion.

Features

  • Hook design allows for use on free-standing studs
  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
  • Electrolytic copper construction offers good conductivity
  • 600V-rated for building wire and 1000V for signs, fixtures or luminaires
  • Funnel-designed sleeve offers easy insertion of wires
  • Vinyl-insulated, butted-seam barrel ensures a secure fit and offers reliable performance

Downloads

Specifications

Maximum Conductor Size (Metric)2.5 mm²
Stud Diameter (Imperial)0.19
Stud Diameter (Metric)4.826
Stud Diameter (Metric) UOMmm
Minimum Conductor Size (Metric)1.5 mm²
Minimum Conductor Size (Imperial)16 AWG
Country of OriginUnited States
Maximum Conductor Size (Imperial)14 AWG
Stud Diameter (Imperial) UOMin
Insulation MaterialNone
