3M Products & Supplies

3M™ Nylon Insulated with Insulation Grip Ring Tongue Terminal, 11-38-NB, standard-style ring tongue fits around the stud - 7100163467

Sold As: 1000-Pack
SKU: 7100163467
MPN: 7100163467
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00054007278924
3M ID: 80601375639
MPN: 11-38-NB
$269.72 ($0.27 / Count)
Hurry up! Current stock:

Product Description

This terminal has a wire range of 8 AWG and a stud size of 1/4. It comes in quantities of 25 per carton and 250 per case.

Features

  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
  • Standard-style ring tongue fits around the stud
  • Nylon-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
  • Made of electrolytic copper for good conductivity and has tin plating for corrosion resistance
  • 600V-rated for building wire and 1000V for signs, fixtures or luminaires
  • Funnel-designed, seamless brass sleeve offers easy insertion of wires

Downloads

Specifications

Minimum Stud Diameter (Imperial) UOMin
Barrel Length (Imperial)0.25 Inch
Maximum Operating Temperature (Celsius) UOMDegree
Terminal TypeRing
Minimum Conductor Size (Imperial)22 AWG
Maximum Operating Temperature (Celsius)175.0
UL File NumberE23438
Minimum Stud Diameter (Metric)9.525
Maximum Conductor Size (Imperial)18 AWG
Minimum Conductor Size (Metric)0.326 mm²
Minimum Stud Diameter (Metric) UOMmm
Ring TypeStandard
Maximum Conductor Size (Metric)0.823
Barrel StyleBrazed
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Connection TypeCrimp
Country of OriginUnited States
Insulation MaterialNylon with Insulation Grip
Terminal StyleStandard
