3M Products & Supplies

3M™ Scotchlok™ Large Gauge Ring Tongue, Copper Non-Insulated Seamless MC2-14RX, Stud Size 1/4, 100/Case - 7100165436

Sold As: 100-Pack
SKU: 7100165436
MPN: 7100165436
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00054007091875
3M ID: 80611607641
5 Digit UPC: 9187
$428.53 ($4.29 / Count)
Hurry up! Current stock:

Product Description

3M™ Scotchlok™ Non-Insulated Copper Seamless Compression Lug Ring Tongue has a non-insulated, seamless barrel and ensures an ideal fit while offering reliable and safe performance. Copper construction offers good conductivity and a tin-plated finish resists corrosion.

Features

  • 600V-rated for building wire
  • Offers electrical connection to a pre-stripped end of a stranded wire
  • Made of copper for good conductivity and has tin plating for corrosion resistance
  • Non-insulated, seamless barrel ensures a secure fit and offers reliable performance
  • UL Listed and RoHS 2011/65/EU Compliant

Downloads

Specifications

Country of OriginUnited States
Connection Width (Imperial)0.25
Connection Width (Metric) UOMmm
Terminal StyleCompression Lugs
Maximum Conductor Size (Metric)2.08
Barrel StyleSeamless
Connection Width (Metric)6.35
Overall Width (Imperial) UOMin
Minimum Conductor Size (Imperial)16 AWG
Overall Width (Imperial)0.65
Maximum Conductor Size (Imperial)14 AWG
Minimum Conductor Size (Metric)1.31 mm²
Terminal TypeRing
Connection Width (Imperial) UOMin
Overall Length (Imperial) UOMin
Overall Length (Imperial)1.69
