3M Products & Supplies

3M™ Scotchlok™ Ring Vinyl Insulated, 100/bottle, MV18-610RX, 500/Case - 7000133344

Sold As: 500-Pack
SKU: 7000133344
MPN: 7000133344
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051128587683
3M ID: 80611464142
5 Digit UPC: 58768
$397.07 ($0.79 / Count)
Hurry up! Current stock:

Product Description

3M™ Scotchlok™ Vinyl Insulated Brazed Seam Multi-Stud Ring Tongue terminal ensures an ideal fit while offering reliable and safe performance. The terminal has a vinyl-insulated, brazed-seam barrel and withstands temperatures of -40 to 221 degrees F (-40 to 105 degrees C). Electrolytic copper construction offers good conductivity and a tin-plated finish resists corrosion.

Features

  • Vinyl-insulated, brazed-seam barrel ensures a secure fit and offers reliable performance
  • Multi-stud style ring tongue fits around multiple stud sizes
  • Funnel-designed, polyvinyl chloride sleeve offers easy insertion of wires
  • UL Listed, CSA Certified and RoHS 2011/65/EU Compliant
  • Made of electrolytic copper for good conductivity and has tin plating for corrosion resistance
  • 600V-rated for building wire and 1000V for signs, fixtures or luminaires

Downloads

Specifications

Country of OriginUnited States
Overall Length (Imperial) UOMin
Maximum Operating Temperature (Celsius)105.0
Overall Length (Metric)25.65
Minimum Conductor Size (Imperial)22 AWG
Maximum Conductor Size (Metric)0.823
Product ColorYellow
Minimum Conductor Size (Metric)0.326 mm²
Overall Length (Imperial)1.01
Terminal TypeRing
Maximum Conductor Size (Imperial)18 AWG
Maximum Operating Temperature (Celsius) UOMDegree
Overall Width (Imperial)0.34
Overall Width (Metric) UOMmm
Overall Width (Imperial) UOMin
Insulation MaterialVinyl
Overall Length (Metric) UOMmm
