3M Products & Supplies

3M™ Thin Flexographic Plate Mounting Tape E2105, Translucent, 36 in x 36 yd, 5 mil, 1 Roll/Case - 7010375957

SKU: 7010375957
MPN: 7010375957
Lead Time: 22 working days.
UPC: 00051115645433
3M ID: 70006743937
5 Digit UPC: 64543
$701.69 each
Hurry up! Current stock:

Product Description

3M™ Thin Flexographic Plate Mounting Tape E2105 is a double coated film tape constructed of a polyester film carrier with differential adhesives. It is specifically designed for mounting flexographic print plates to cushioned or compressible sleeves.

Features

  • 0.005 inch (0.13 mm) double coated tape has the air release feature designed to allow air to escape from between the tape and the plate
  • Non-linered side of the tape is designed for mounting to compressible sleeves
  • Securely bonds the flexographic photopolymer plate to the compressible sleeve to prevent plate edge lifting during printing
  • Clean removal from both the plate and the sleeve
Spec Sheet



Downloads

Specifications

Shelf Life365
Country of OriginUnited States
Primary Liner Thickness (Metric) UOMmm
Primary LinerPolycoated Kraft Paper
Air ReleaseYes
Overall Width (Imperial) UOMin
Primary Liner Thickness (Imperial) UOMmil
Overall Length (Imperial)36.0
Product FormRoll
Product ColorTransparent
Primary Liner Thickness (Metric)0.101
Units per Case1.0
Application Thickness (Imperial) UOMmil
Clean RemovalYes
Overall Length (Metric)32.91
Shelf Life UOMMonth
Overall Length (Imperial) UOMyd
Primary Liner Thickness (Imperial)4.0
Urethane SleevesNo
Overall Width (Metric)914.4
Overall Width (Metric) UOMmm
Overall Length (Metric) UOMm
Adhesive TypeDifferential Acrylate
Backing MaterialPolyester Film
Overall Width (Imperial)36.0
IndustriesPrint
Application Thickness (Imperial)5
ApplicationFlexographic Plate Mounting
Product CategoryFlexographic Plate Mounting Tapes
