3M Products & Supplies

3M™ VHB™ Tape 4910, Clear, 1/2 in x 36 yd, 40 mil, Small Pack, 4 rolls per case - 7000123482

Sold As: 4-Pack
SKU: 7000123482
MPN: 7000123482
For an accurate lead time please contact us
UPC: 021200645884
3M ID: 70006147071
5 Digit UPC: 64588
$341.19 ($85.30 / Count)
Hurry up! Current stock:

Product Description

Dream, Design, Deliver with 3M™ VHB™ Tape 4910. It is a clear, 0.040 in (1.0 mm), general purpose acrylic adhesive on both sides of a firm, foam core. It can replace rivets, welds and screws. The fast and easy to use permanent bonding method provides high strength and long-term durability. It offers design flexibility with its viscoelasticity and powerful ability to bond to a variety of surfaces.

Features

  • Virtually invisible fastening keeps surfaces smooth
  • Creates a permanent seal against water, moisture and more
  • Clear, 0.040 in (1.0 mm), general purpose adhesive and firm acrylic foam core offers a good balance of strength and conformability
  • Pressure sensitive adhesive bonds on contact to provide immediate handling strength
  • Fast and easy-to-use permanent bonding method provides high strength and long-term durability
  • Can replace mechanical fasteners (rivets, welds, screws) or liquid adhesives for transparent applications
  • Eliminate drilling, grinding, refinishing, screwing, welding and associated clean-up
  • Allows the use of thinner, lighter weight and dissimilar materials

Downloads

Specifications

Substrate 1Paint - High Surface Energy Plastic - Metal - Glass - Sealed Wood
Primary LinerPolyethylene (PE) Film
Application Temperature-Environment (Metric)10 Degree Celsius
Product ColorTransparent
Substrate 2HSE Plastics and Glass - Rough Surfaces - Glass - Painted Surface, Easy-to-Bond (HSE) - Plastic, Easy-to-Bond (HSE) - Paint - Bare Metal - Metal - High Surface Energy Plastic - Sealed Wood
Overall Length (Metric)32.9 m
Backing (Carrier) MaterialAcrylic Foam
Overall Length (Imperial)36 yd
Maximum Operating Temperature (Fahrenheit)200 Degree Fahrenheit
Overall Thickness (Metric)1 mm
Overall Width (Metric)12.7 mm
Indoor/OutdoorIndoor/Outdoor
Temperature Resistance - Initial300 Degree Fahrenheit
Overall Thickness (Imperial)40 mil
Foam ConformabilityFirm
Overall Width (Imperial)0.5 in
SubstratePaint - Glass - Medium-High Surface Energy, (42-50 Dynes/cm) - Rough Surfaces - High Surface Energy, (400-1100 Dynes/cm) - HSE Plastics and Glass - Metal
Product Key4910
Backing Thickness (Imperial)5 mil
Product FormRoll
Backing MaterialFoam
Foam TypeFirm
Adhesive TypeAcrylic
Set Time
Backing (Carrier) Thickness (Imperial)5 mil
Core Size (Imperial)3 in
Application Temperature-Environment50 Degrees Fahrenheit
Design ChallengesNoise Vibration & Harshness Control NVH - Impact & Shock Absorption
Product Number4910
Carrier MaterialAcrylic Foam
Primary Liner Thickness (Imperial)5 mil
Maximum Operating Temperature (Celsius)149 Degree Celsius
