3M Products & Supplies

3M™ Vibration Damping Tape 434, Silver, 8 in x 60 yd, 7.5 mil, 1 Roll/Case - 7010374435

Sold As: 4-Pack
SKU: 7010374435
MPN: 7010374435
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051138953836
3M ID: 70006388006
5 Digit UPC: 95383
$5,146.42 ($1286.61 / Count)
Hurry up! Current stock:

Product Description

3M™ Vibration Damping Tape 434 is a low temperature, silver, dead soft aluminum foil tape. The constraining layer is coated with a pressure sensitive viscoelastic polymer on a blue polyethylene easy release liner. This tape absorbs and dissipates vibration and reduces noise. It is useful for a variety of applications in the aerospace, automotive, construction, appliance and MRO industries.

Features

  • Viscoelastic acrylic polymer adhesive is optimized to convert vibrational energy to negligible heat that readily dissipates
  • Resists weather and UV degradation, ensuring performance in many difficult applications
  • Vibration damping properties make this tape an ideal choice for a variety of applications in industries such as aerospace, transportation, appliance, general industrial and more
  • Linered construction offer diecutting capabilities
  • Cold temperature resistance allows tape to perform at extremely low temperatures (-76°F/-60°C)
Spec Sheet



Downloads

Specifications

Shelf Life730
Country of OriginUnited States
Overall Length (Imperial) UOMyd
Maximum Operating Temperature (Celsius)20.0
Maximum Operating Temperature (Fahrenheit) UOMDegree
Units per Case1.0
Maximum Operating Temperature (Fahrenheit)68.0
Minimum Operating Temperature (Fahrenheit)-76.0
Overall Length (Imperial)60.0
Minimum Operating Temperature (Celsius) UOMDegree
Backing (Carrier) Thickness (Imperial) UOMmil
Product ColorSilver
Overall Width (Imperial)8.0
Tensile Strength (Imperial) UOMoz/in
Overall Width (Metric)203.2
ApplicationVibration Damping
Overall Width (Metric) UOMmm
Backing (Carrier) Thickness (Metric) UOMmm
Tensile Strength (Imperial)800.0
Tensile Strength (Metric)87.6
Minimum Operating Temperature (Celsius)-60.0
Maximum Operating Temperature (Celsius) UOMDegree
Backing (Carrier) Thickness (Metric)0.14
Back Side Adhesive Thickness (Metric)0.14
Minimum Operating Temperature (Fahrenheit) UOMDegree
Total Tape Thickness without Liner (Metric) UOMmm
IndustriesAerospace, Appliance, Automotive, Construction, Electronics, General Industrial, Metalworking, Military and Government, Specialty Vehicles, Transportation
Total Tape Thickness without Liner (Imperial) UOMmil
Elongation at Break12
Back Side Adhesive Thickness (Metric) UOMmm
Overall Width (Imperial) UOMin
Total Tape Thickness without Liner (Imperial)5.5
Total Tape Thickness without Liner (Metric)0.14
Backing MaterialAluminum Foil
Adhesive TypeViscoelastic Polymer
Overall Length (Metric)54.86
Primary LinerPolyethylene
Overall Length (Metric) UOMm
Backing (Carrier) Thickness (Imperial)5.5
Shelf Life UOMMonth
Tensile Strength (Metric) UOMN/100mm
