3M Products & Supplies

3M™ Vinyl Insulated Butted Seam Ring Tongue Terminal 12-14S-P, standard-style ring tongue fits around the stud - 7100163568

Sold As: 1000-Pack
SKU: 7100163568
MPN: 7100163568
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00054007283089
3M ID: 80601380001
MPN: 12-14S-P
$121.30 ($0.12 / Count)
Hurry up! Current stock:

Product Description

This terminal has a wire range of 8 AWG and a stud size of 1/4. It comes in quantities of 25 per carton and 250 per case.

Features

  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
  • Nylon-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
  • Funnel-designed, seamless brass sleeve offers easy insertion of wires
  • Standard-style ring tongue fits around the stud
  • 600V-rated for building wire and 1000V for signs, fixtures or luminaires
  • Made of electrolytic copper for good conductivity and has tin plating for corrosion resistance

Downloads

Specifications

Ring TypeStandard
Maximum Operating Temperature (Celsius)175.0
Minimum Stud Diameter (Metric)6.35
Maximum Conductor Size (Imperial)14 AWG
Minimum Conductor Size (Imperial)16 AWG
Terminal TypeRing
Maximum Conductor Size (Metric)2.08
Barrel Length (Imperial)0.25 Inch
UL File NumberE23438
Minimum Stud Diameter (Imperial) UOMin
Connection TypeCrimp
Insulation MaterialVinyl
Barrel StyleBrazed
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Minimum Stud Diameter (Metric) UOMmm
Country of OriginUnited States
Maximum Operating Temperature (Celsius) UOMDegree
Minimum Conductor Size (Metric)1.31 mm²
Terminal StyleStandard
