3M Products & Supplies

3M™ Vinyl Tape 471, Orange, 1 in x 36 yd, 5.2 mil, 36 Roll/Case - 7000122477

Sold As: 36-Pack
SKU: 7000122477
MPN: 7000122477
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00021200031403
3M ID: 70002415050
5 Digit UPC: 3140
$831.74 ($23.10 / Count)
Hurry up! Current stock:

Product Description

3M™ Vinyl Tape 471 is a versatile tape that provides long-lasting floor marking, sharp paint lines, surface protection, and reliable seals in complex situations across a variety of industries. Engineered with unique stretch properties, this tape conforms to rough, irregular, curved, and convex surfaces without lifting. It uses a rubber adhesive that bonds immediately and removes cleanly on a wide variety of substrates. Made for high performance, the vibrant backing resists abrasion, moisture, and solvents. Conformability, instant adhesion, and clean removal all make 3M™ Vinyl Tape 471 an exceptional choice for general-purpose surface protection, floor marking, hazard identification, paint masking, and decorating.

Features

  • COMES OFF CLEAN: Engineered for tidy, one-piece removal to minimize cleanup and labor
  • UNIQUE STRETCHABILITY: Slight elasticity helps this tape tightly conform to uneven surfaces without lifting and retracting
  • VIVID COLOR: A wide variety of colors helps markup floors and protect surfaces with color-coded efficiency
  • LONG SERVICE LIFE: Mark and protect surfaces longer thanks to construction that resists abrasion and solvents
  • POWERFUL ADHESIVE: Rubber adhesive provides excellent holding strength on most surfaces
  • EXCELLENT SEALING: A combination of versatile adhesive and chemical resistant backing can create a robust long or short term seal
Spec Sheet



Downloads

Specifications

Shelf Life547
Country of OriginUnited States
Overall Height (Imperial)5.2
Overall Height (Metric) UOMmm
Performance LevelHigh Performance
Minimum Operating Temperature (Fahrenheit) UOMDegree
Backing (Carrier) MaterialVinyl
Backing (Carrier) Thickness (Metric) UOMmm
Overall Thickness (Imperial) UOMmil
Overall Thickness (Imperial)5.3
Total Tape Thickness without Liner (Imperial) UOMmil
Dielectric Strength0.0
Backing MaterialVinyl
Total Tape Thickness without Liner (Imperial)5.2
Minimum Operating Temperature (Celsius) UOMDegree
Maximum Operating Temperature (Fahrenheit)170.0
Overall Length (Metric) UOMm
Tensile Strength (Metric) UOMN/100mm
Elongation at Break1.3%
Tensile Strength (Imperial)14.0
Maximum Operating Temperature (Celsius) UOMDegree
Maximum Operating Temperature (Fahrenheit) UOMDegree
Back Side Adhesive Thickness (Metric)0.03
Product ColorOrange
Tensile Strength (Imperial) UOMlb/in
Back Side Adhesive Thickness (Imperial)1.1
Adhesion Strength26.0
Shelf Life in Months (From Date of Manufacture) UOMMonths
Tensile Strength (Metric)24.5
Backing Thickness (Imperial)4.1
Overall Width (Metric) UOMcm
Adhesive TypeRubber
Overall Width (Imperial)1.0
Overall Height (Imperial) UOMmil
Shelf Life in Months (From Date of Manufacture)18.0
Backing Thickness (Metric)0.1
Adhesion Strength (Metric)28.0
Tape Thickness (Imperial)5.2
Backing (Carrier) Thickness (Metric)0.1
Total Tape Thickness without Liner (Metric) UOMmm
ApplicationPaint Preparation Masking
Backing (Carrier) Thickness (Imperial) UOMmil
Accessory TypeTape
Overall Width (Metric)2.5
Back Side Adhesive Thickness (Metric) UOMmm
Overall Length (Imperial) UOMyd
Overall Length (Metric)32.9
Overall Width (Imperial) UOMin
Adhesive MaterialRubber
Back Side Adhesive Thickness (Imperial) UOMmil
Self-extinguishingNo
IndustriesAutomotive, General Industrial, MRO, Military and Government, Specialty Vehicles, Transportation
Backing Thickness (Imperial) UOMmil
Product FormRoll
Shelf Life UOMMonth
Backing Thickness (Metric) UOMmm
Units per Case36.0
Units per Case UOMRoll
Maximum Operating Temperature (Celsius)76.0
Overall Length (Imperial)36.0
Adhesion Strength (Metric) UOMN/100mm
Total Tape Thickness without Liner (Metric)0.14
Backing (Carrier) Thickness (Imperial)4.1
Minimum Operating Temperature (Celsius)4.0
Overall Height (Metric)0.1
Minimum Operating Temperature (Fahrenheit)40.0
