3M Products & Supplies

3M™ Vinyl Tape 471, Transparent, 1 1/2 in x 36 yd, 5.2 mil, 24 Roll/Case - 7000047449

Sold As: 24-Pack
SKU: 7000047449
MPN: 7000047449
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00021200031014
3M ID: 70002408063
5 Digit UPC: 3101
$831.64 ($34.65 / Count)
Hurry up! Current stock:

Product Description

3M™ Vinyl Tape 471 is a versatile tape that provides temporary or long-lasting surface protection and reliable seals in complex situations across a variety of industries. Engineered with unique stretch properties, this tape conforms to rough, irregular, curved, and convex surfaces without lifting. It uses a rubber adhesive that bonds immediately and removes cleanly on a wide variety of substrates. Made for high performance, the see-through backing resists abrasion, moisture, and solvents. Conformability, instant adhesion, and clean removal all make transparent 3M™ Vinyl Tape 471 an exceptional choice for sealing, general-purpose surface protection, and bundling.

Features

  • Rubber adhesive provides excellent holding strength on many surfaces
  • Unique stretch properties enable tape to remain stretched to conform to uneven surfaces without lifting and retracting
  • This is the transparent version of the product
  • Available in a wide variety of vivid colors for diverse applications such as floor marking, paint masking, and surface protection
  • One-piece, clean removal from many surfaces which helps reduce clean-up and labor costs
  • Good abrasion and solvent resistance for long service life
Spec Sheet



Downloads

Specifications

Shelf Life547
Country of OriginUnited States
Overall Height (Metric) UOMmm
Overall Height (Metric)0.1
Backing Thickness (Imperial) UOMmil
Overall Height (Imperial) UOMmil
Backing (Carrier) MaterialPVC
Total Tape Thickness without Liner (Metric) UOMmm
Shelf Life in Months (From Date of Manufacture) UOMMonths
Total Tape Thickness without Liner (Imperial) UOMmil
Overall Length (Imperial) UOMyd
Tensile Strength (Imperial) UOMlb/in
Backing (Carrier) Thickness (Metric)0.1
Overall Width (Metric) UOMcm
Backing Thickness (Metric)0.1
Overall Height (Imperial)5.2
Backing Thickness (Imperial)4.1
Elongation at Break1.3%
Minimum Operating Temperature (Celsius) UOMDegree
Maximum Operating Temperature (Fahrenheit) UOMDegree
Overall Length (Metric) UOMm
Backing (Carrier) Thickness (Metric) UOMmm
Tensile Strength (Metric) UOMN/100mm
Adhesion Strength26.0
Overall Width (Imperial) UOMin
Maximum Operating Temperature (Celsius) UOMDegree
Tensile Strength (Metric)270.0
Backing (Carrier) Thickness (Imperial) UOMmil
Tensile Strength (Imperial)14.0
Maximum Operating Temperature (Fahrenheit)170.0
Back Side Adhesive Thickness (Imperial) UOMmil
ApplicationColor Coding Tools & Equipment; Electroplating and Anodizing Processes; Fine Line Masking; Floor and Safety Marking; General Use Vinyl; Paint Masking; Safety & Hazard Marking; Sealing; Sealing Plate Edges Against Ink Penetration
Overall Thickness (Imperial)5.3
Product ColorTransparent
Backing MaterialVinyl
Back Side Adhesive Thickness (Imperial)1.1
Overall Thickness (Imperial) UOMmil
Maximum Operating Temperature (Celsius)77.0
Performance LevelHigh Performance
Total Tape Thickness without Liner (Metric)0.132
Units per Case24.0
Backing (Carrier) Thickness (Imperial)4.1
Minimum Operating Temperature (Fahrenheit) UOMDegree
Back Side Adhesive Thickness (Metric)0.03
Shelf Life in Months (From Date of Manufacture)18.0
Overall Width (Imperial)1.5
Adhesion Strength (Metric)28.0
Adhesive TypeRubber
Overall Width (Metric)3.8
Product FormRoll
IndustriesAutomotive, General Industrial, MRO, Military and Government, Specialty Vehicles, Transportation
Back Side Adhesive Thickness (Metric) UOMmm
Overall Length (Metric)32.9
Overall Length (Imperial)36.0
Backing Thickness (Metric) UOMmm
Minimum Operating Temperature (Fahrenheit)40.0
Adhesion Strength (Metric) UOMN/100mm
Units per Case UOMRoll
Minimum Operating Temperature (Celsius)4.0
Total Tape Thickness without Liner (Imperial)5.2
