3M Products & Supplies

3M™ Vinyl Tape 471, Transparent, 2 in x 36 yd, 5.2 mil, 24 Roll/Case, Individually Wrapped Conveniently Packaged - 7100044331

Sold As: 24-Pack
SKU: 7100044331
MPN: 7100044331
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051115688232
3M ID: 70006747698
5 Digit UPC: 68823
$1,122.13 ($46.76 / Count)
Hurry up! Current stock:

Product Description

3M™ Vinyl Tape 471 is a versatile tape that provides temporary or long-lasting surface protection and reliable seals in complex situations across a variety of industries. Engineered with unique stretch properties, this tape conforms to rough, irregular, curved, and convex surfaces without lifting. It uses a rubber adhesive that bonds immediately and removes cleanly on a wide variety of substrates. Made for high performance, the see-through backing resists abrasion, moisture, and solvents. Conformability, instant adhesion, and clean removal all make transparent 3M™ Vinyl Tape 471 an exceptional choice for sealing, general-purpose surface protection, and bundling.

Features

  • Good abrasion and solvent resistance for long service life
  • One-piece, clean removal from many surfaces which helps reduce clean-up and labor costs
  • Unique stretch properties enable tape to remain stretched to conform to uneven surfaces without lifting and retracting
  • Rubber adhesive provides excellent holding strength on many surfaces
  • Available in a wide variety of vivid colors for diverse applications such as floor marking, paint masking, and surface protection
  • This is the transparent version of the product
Spec Sheet



Downloads

Specifications

Shelf Life547
Country of OriginUnited States
Units per Case UOMRoll
Tensile Strength (Metric)270.0
Maximum Operating Temperature (Celsius) UOMDegree
Overall Height (Metric) UOMmm
Overall Length (Metric) UOMm
Back Side Adhesive Thickness (Metric)0.03
Overall Height (Imperial)5.2
Minimum Operating Temperature (Celsius)4.0
Tensile Strength (Imperial)14.0
Adhesion Strength (Metric) UOMN/100mm
IndustriesAutomotive, General Industrial, MRO, Military and Government, Specialty Vehicles, Transportation
Backing (Carrier) Thickness (Metric)0.1
Minimum Operating Temperature (Fahrenheit)40.0
Overall Length (Metric)32.9
ApplicationColor Coding Tools & Equipment; Electroplating and Anodizing Processes; Fine Line Masking; Floor and Safety Marking; General Use Vinyl; Paint Masking; Safety & Hazard Marking; Sealing; Sealing Plate Edges Against Ink Penetration
Backing Thickness (Imperial) UOMmil
Tensile Strength (Imperial) UOMlb/in
Performance LevelHigh Performance
Overall Length (Imperial) UOMyd
Maximum Operating Temperature (Fahrenheit) UOMDegree
Elongation at Break1.3%
Backing Thickness (Metric) UOMmm
Adhesion Strength26.0
Adhesion Strength (Metric)28.0
Overall Height (Imperial) UOMmil
Shelf Life in Months (From Date of Manufacture)18.0
Total Tape Thickness without Liner (Metric)0.14
Total Tape Thickness without Liner (Metric) UOMmm
Overall Width (Imperial)2.0
Overall Length (Imperial)36.0
Maximum Operating Temperature (Fahrenheit)170.0
Overall Height (Metric)0.1
Back Side Adhesive Thickness (Imperial)1.1
Product FormRoll
Tensile Strength (Metric) UOMN/100mm
Product ColorTransparent
Shelf Life in Months (From Date of Manufacture) UOMMonths
Overall Width (Metric) UOMcm
Minimum Operating Temperature (Celsius) UOMDegree
Backing Thickness (Metric)0.1
Total Tape Thickness without Liner (Imperial) UOMmil
Total Tape Thickness without Liner (Imperial)5.2
Backing MaterialVinyl
Overall Width (Metric)5.1
Backing (Carrier) Thickness (Imperial)4.1
Maximum Operating Temperature (Celsius)77.0
Backing (Carrier) Thickness (Imperial) UOMmil
Overall Thickness (Imperial) UOMmil
Units per Case24.0
Backing (Carrier) Thickness (Metric) UOMmm
Overall Width (Imperial) UOMin
Back Side Adhesive Thickness (Metric) UOMmm
Back Side Adhesive Thickness (Imperial) UOMmil
Backing Thickness (Imperial)4.1
Overall Thickness (Imperial)5.2
Minimum Operating Temperature (Fahrenheit) UOMDegree
Backing (Carrier) MaterialPVC
Adhesive TypeRubber
