Pipe milling cutter for pipes from dia. 10 [250] in[mm] to dia. 59 [1,500] in[mm]|RDG 1500 B - 75602761000
primary_image
video
Previous Next

Fein Power Tools

Pipe milling cutter for pipes from dia. 10 [250] in[mm] to dia. 59 [1,500] in[mm]|RDG 1500 B - 75602761000

SKU: 75602761000
MPN: 75602761000
Stock Item: Stock items typically ship within 2-3 business days
UPC: 4014586889269
Availability: 1
$36,066.95
Hurry up! Current stock:

Product Description

Pipe milling cutter for pipes from dia. 10 [250] in[mm] to dia. 59 [1,500] in[mm]|RDG 1500 B|Powerful compressed air pipe-milling machine with a feed rate of 3-1/8 [80] in/min[mm/min] for pipes up to dia. 59 [1,500] in[mm].

Features

  • Cutting of gray cast iron water pipes up to a wall thickness of 9/16 [15] in[mm].
  • Simple setup/shortened side plates ensure less space is required around the machine. In addition, weight optimization means that only two persons are required to set up the machine.
  • The optionally available guide chain guarantees straight cuts without offset.
  • Horizontal and vertical dividing without extra investment.
  • Motor drive parts in stainless construction. The pneumatic motor’s vents are resistant to swelling.
  • Sawing of steel and gray cast iron water pipes up to a wall thickness of 7/8 [22] in[mm].
  • Operation in low water possible after test.

Specifications

Motor no-load speed6,000 rpm
Weight (lbs)149.91
Operating pressure (bar)6
Tool no-load speed70 rpm
Advance3.15 [80] mm in[mm] /min
Operating pressure (psi)87
Power output2,000 W
Air consumption (cfm)151.9
Weight (kg)68
Air consumption (m³/min)4.3
