3M Products & Supplies

3M™ PTFE Film Tape 5480, Gray, 4 in x 36 yd, 3 Roll/Case - 7000048615

Sold As: 3-Pack
SKU: 7000048615
MPN: 7000048615
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00021200649615
3M ID: 70006162120
$1,701.54 ($567.18 / Count)
Hurry up! Current stock:

Product Description

3M™ PTFE Skived Film Tape 5480 uses a skived, polytetrafluoroethylene (PTFE), conformable film backing. This tape offers an extremely low coefficient of friction which, in combination with a pressure sensitive silicone adhesive, creates a smooth, non-stick surface over a variety of substrates to assist in the movement of web materials in many types of roll-wrap applications.

Features

  • Skived 3M™ PTFE Film Tapes are more conformable than typical extruded PTFE film tapes
  • Silicone adhesive provides clean removal from a variety of surfaces
  • Non-stick PTFE film provides an exceptionally slick surface for easy clean-up
  • Excellent chemical resistance enables tape to withstand challenging applications
  • Wide temperature range for performance on heated machinery and equipment
Spec Sheet



Downloads

Specifications

Minimum Operating Temperature (Fahrenheit)-65.0
Units per Case3.0
Overall Length (Metric) UOMm
Backing (Carrier) MaterialSkived PTFE
Tensile Strength (Imperial) UOMlb/in
Total Tape Thickness without Liner (Metric) UOMmm
Product ColorGray
Tensile Strength (Imperial)27.0
Units per Case UOMRoll
Maximum Operating Temperature (Celsius) UOMDegree
Minimum Operating Temperature (Fahrenheit) UOMDegree
Maximum Operating Temperature (Celsius)260.0
Minimum Operating Temperature (Celsius)-54.0
Overall Length (Imperial)36.0
Overall Length (Imperial) UOMyd
Minimum Operating Temperature (Celsius) UOMDegree
Country of OriginUnited States
Overall Width (Imperial) UOMin
Total Tape Thickness without Liner (Imperial)3.7
Adhesive TypeSilicone
Total Tape Thickness without Liner (Metric)0.09
Backing (Carrier) Thickness (Imperial) UOMmil
Maximum Operating Temperature (Fahrenheit) UOMDegree
Total Tape Thickness without Liner (Imperial) UOMmil
IndustriesAerospace
Maximum Operating Temperature (Fahrenheit)500.0
Tensile Strength (Metric) UOMN/100mm
Overall Width (Imperial)4.0
Backing (Carrier) Thickness (Metric) UOMmm
Backing (Carrier) Thickness (Metric)0.05
Overall Length (Metric)32.9
Overall Width (Metric)10.2
Tensile Strength (Metric)46.1
Overall Width (Metric) UOMcm
ApplicationCovering Wrapping Rollers; Paper & Film Tracking
Backing (Carrier) Thickness (Imperial)2.0
