3M Products & Supplies

3M™ Adhesive Transfer Tape 9502, Clear, 24 in x 180 yd, 2 mil, 1 Roll/Case - 7000123420

SKU: 7000123420
MPN: 7000123420
Stock Item: Stock items typically ship within 2-3 business days
UPC: 00021200684357
3M ID: 70006103736
5 Digit UPC: 68435
$846.24 each
Hurry up! Current stock:

Product Description

3M™ Adhesive Transfer Tape 9502 features 3M™ Industrial Acrylic Adhesive 220, which provides a good bond to HSE materials. This 2.3 mil adhesive is applied to a 4.2 mil polycoated kraft (PCK) paper liner, which protects it until it is ready to be bonded to the substrate.

Features

  • PCK liner protects adhesive and peels away quickly for easy handling
  • 2 mil nominal 220 adhesive offers good sheer strength
  • Economical solution for a variety of general bonding applications
  • Good peel adhesion to HSE (high surface energy) materials
Spec Sheet



Downloads

Specifications

Shelf Life730
Country of OriginUnited States
Primary Liner Thickness (Imperial)4.2
Units per Case UOMRoll
Overall Length (Imperial) UOMyd
Overall Width (Metric) UOMmm
Maximum Operating Temperature (Celsius)177.0
Minimum Operating Temperature (Celsius) UOMDegree
Primary Liner Thickness (Imperial) UOMmil
Overall Length (Metric)164.59
Overall Width (Metric)609.6
Minimum Operating Temperature (Fahrenheit)-40.0
Units per Case1.0
Primary Liner Thickness (Metric) UOMmm
Shelf Life UOMMonth
Maximum Operating Temperature (Fahrenheit) UOMDegree
IndustriesAerospace, Automotive, Converter Solutions, Electronics, General Industrial, Metalworking, Point of Purchase, Print, Signage, Woodworking
Primary Liner58# Polycoated Kraft Paper
Maximum Operating Temperature (Fahrenheit)350.0
Primary Liner Thickness (Metric)0.11
Total Tape Thickness without Liner (Metric) UOMmm
Overall Width (Imperial)24.0
Total Tape Thickness without Liner (Imperial)2.0
Overall Length (Metric) UOMm
Maximum Operating Temperature (Celsius) UOMDegree
Overall Width (Imperial) UOMin
Total Tape Thickness without Liner (Imperial) UOMmil
Indoor/OutdoorIndoor/Outdoor
Minimum Operating Temperature (Fahrenheit) UOMDegree
Total Tape Thickness without Liner (Metric)0.051
Adhesive TypeAcrylic
Minimum Operating Temperature (Celsius)-40.0
Product CategoryAdhesives
Primary Liner ColorTan
Overall Length (Imperial)180.0
