3M™ Adhesive Transfer Tape Double Linered 7955MP, Clear, 24 in x 36 in, 5 mil, 100 Sheet/Case - 7000001568

SKU: 7000001568
MPN: 7000001568
Stock Item: Stock items typically ship within 2-3 business days
UPC: 50021200184104
3M ID: 70016034699
5 Digit UPC: 18410
$1,393.55 each
Hurry up! Current stock:

Product Description

3M™ Adhesive Transfer Tape Double Linered 7952MP provides outstanding adhesion to metal and high surface energy plastics. 200MP adhesive delivers excellent shear strength to resist slippage and edge lifting. The tape is temporarily repositionable for placement accuracy. It also performs well after exposure to humidity and hot/cold temperatures. Double 58 lb. PCK liners add dimensional stability.

Features

  • 5 mil nominal adhesive tape delivers exceptional shear strength for metals and HSE plastics
  • Temporarily repositionable adhesive improves placement accuracy, reducing rework
  • Double 4.2 mil PCK layflat liner virtually eliminates curling, buckling and rippling
  • 200MP acrylic adhesive is considered the industry standard for graphic attachment and general industrial joining applications
  • Special PCK layflat liner for increased dimensional stability in high humidity storage, processing, shipping and application conditions
  • Provides very high resistance to solvents and humidity
Spec Sheet



Downloads

Specifications

Shelf Life730
Country of OriginUnited States
Overall Width (Metric)609.6
Primary Liner Thickness (Imperial) UOMmil
Total Tape Thickness without Liner (Imperial)5.0
Primary Liner ColorTan
Secondary Liner58# Polycoated Kraft Paper
Overall Width (Imperial)24.0
Primary Liner58# Polycoated Kraft Paper
Secondary Liner Thickness (Metric) UOMmm
Maximum Operating Temperature (Fahrenheit) UOMDegree
Overall Length (Imperial) UOMin
Maximum Operating Temperature (Fahrenheit)400.0
Adhesive TypeAcrylic
Units per Case100.0
Overall Length (Metric)0.91
Minimum Operating Temperature (Fahrenheit) UOMDegree
Secondary Liner Thickness (Metric)0.11
Primary Liner Thickness (Imperial)4.2
Primary Liner Thickness (Metric) UOMmm
Total Tape Thickness without Liner (Metric) UOMmm
Minimum Operating Temperature (Fahrenheit)-40.0
Indoor/OutdoorIndoor/Outdoor
Overall Width (Metric) UOMmm
Units per Case UOMRoll
Secondary Liner Thickness (Imperial)4.2
Overall Length (Metric) UOMmm
Overall Width (Imperial) UOMin
Total Tape Thickness without Liner (Metric)0.132
Minimum Operating Temperature (Celsius) UOMDegree
Shelf Life UOMMonth
Secondary Liner ColorTan
Minimum Operating Temperature (Celsius)-40.0
Overall Length (Imperial)36.0
Total Tape Thickness without Liner (Imperial) UOMmil
Maximum Operating Temperature (Celsius) UOMDegree
Primary Liner Thickness (Metric)0.11
IndustriesAerospace, Appliance, Automotive, Converter Solutions, Electronics, General Industrial, MRO, Medical, Metalworking, Military and Government, Point of Purchase, Print, Signage, Specialty Vehicles, Transportation, Woodworking
Secondary Liner Thickness (Imperial) UOMmil
Maximum Operating Temperature (Celsius)204.0
