3M Products & Supplies

3M™ Adhesive Transfer Tape Double Linered 9555, Clear, 24 in x 36 in, 5 mil, 100 Sheet/Case - 7000048662

Sold As: 40-Pack
SKU: 7000048662
MPN: 7000048662
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 50021200311029
3M ID: 70006188257
5 Digit UPC: 31102
$41,805.79 ($1045.14 / Count)
Hurry up! Current stock:

Product Description

3M™ Adhesive Transfer Tape Double Linered 9555 features 3M™ Industrial Acrylic Adhesive 220, which provides a good bond to HSE materials. This 5.0 mil adhesive is applied to a 4.2 mil polycoated kraft (PCK) paper liner, which protects it until it is ready to be bonded to the substrate.

Features

  • Good peel adhesion to HSE (high surface energy) materials
  • 5 mil nominal 220 adhesive offers good sheer strength
  • Two 58 lb. PCK liners protect adhesive and peel away quickly for easy handling
  • Thicker adhesives improve wet-out and adhesion on textured surfaces
  • Economical solution for a variety of general bonding applications
Spec Sheet



Downloads

Specifications

Shelf Life730
Country of OriginUnited States
Primary Liner Thickness (Metric) UOMmm
Shelf Life UOMMonth
Overall Width (Metric)609.6
Overall Length (Imperial)36.0
Maximum Operating Temperature (Fahrenheit)350.0
Units per Case UOMRoll
Total Tape Thickness without Liner (Imperial) UOMmil
Overall Width (Imperial) UOMin
IndustriesAerospace, Automotive, Converter Solutions, Electronics, General Industrial, Metalworking, Point of Purchase, Print, Signage, Woodworking
Total Tape Thickness without Liner (Metric) UOMmm
Primary Liner Thickness (Imperial)4.2
Minimum Operating Temperature (Fahrenheit)-40.0
Primary Liner Thickness (Imperial) UOMmil
Overall Width (Metric) UOMmm
Secondary Liner Thickness (Imperial)4.2
Adhesive TypeAcrylic
Total Tape Thickness without Liner (Imperial)5.0
Secondary Liner58# Polycoated Kraft Paper
Overall Width (Imperial)24.0
Secondary Liner Thickness (Metric) UOMmm
Overall Length (Metric)914.4
Overall Length (Imperial) UOMin
Total Tape Thickness without Liner (Metric)0.12
Minimum Operating Temperature (Fahrenheit) UOMDegree
Units per Case100.0
Maximum Operating Temperature (Fahrenheit) UOMDegree
Primary Liner58# Polycoated Kraft Paper
Overall Length (Metric) UOMmm
Secondary Liner Thickness (Metric)0.11
Secondary Liner ColorTan
Secondary Liner Thickness (Imperial) UOMmil
Primary Liner Thickness (Metric)0.11
Primary Liner ColorTan
