3M Products & Supplies

3M™ Automotive Heat Shrink Tubing SMS, .700 inch I.D., Orange Squares, 75 mm Length, 1000 each per carton, 1000/Case - 7010304024

Sold As: 1000-Pack
SKU: 7010304024
MPN: 7010304024
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051135446720
3M ID: 80611002504
5 Digit UPC: 44672
$1,013.35 ($1.01 / Count)
Hurry up! Current stock:

Product Description

3M™ Heat Shrink Tubing SMS is a dual wall tubing that is specially designed for automotive wire harnesses. This tubing has a 4:1 shrink ratio and semi rigid polyolefin construction with an internal layer of thermoplastic adhesive offers moisture seal protection.

Features

  • Specially designed for automotive wire harnesses
  • Flame-retardant
  • Made of semi-rigid polyolefin with colored squares
  • RoHS 2011/65/EU Compliant
  • Suitable for insulation of RV, truck, tractor, heavy equipment and marine wire splices, in-line components, fusible links and terminals
  • Withstands temperatures of -67 to 230 degrees F (-55 to 110 degrees C)
Spec Sheet



Downloads

Specifications

Shelf Life3600
Country of OriginUnited States
Maximum Operating Temperature (Fahrenheit)230.0
Product ColorOrange
Inner Diameter After Shrink (Metric) UOMmm
Maximum Operating Temperature (Celsius)110.0
Operating Temperature Range (Celsius)-55 °C to +135 °C
Inner Diameter After Shrink (Metric)4.44
Maximum Operating Temperature (Celsius) UomDegree
Maximum Operating Temperature (Fahrenheit) UOMDegree
Non-CorrosiveYes
Inner Diameter Before Shrink (Metric)17.78
Overall Length (Imperial) UOMin
MaterialAdhesive-lined, Semi-rigid Polyolefin
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Color CodedOrange
Shrink Ratio4:1
Overall Length (Imperial)48.0
Inner Diameter After Shrink (Imperial)0.175
Inner Diameter Before Shrink (Imperial) UOMin
Tubing TypeAdhesive-Lined, Environmental Protection Sleeve-Semi Rigid
Inner Diameter After Shrink (Imperial) UOMin
Inner Diameter Before Shrink (Metric) UOMmm
Elongation UOM%
Inner Diameter Before Shrink (Imperial)0.7
Mil SpecAMS-DTL-23053/4, Class 3
Heat Shrink TypeAdhesive-Lined Polyolefin Heat Shrink Tubing
