3M Products & Supplies

3M™ Conformable Sound Management Film Tape 9343, Black, 1 in x 36 yd, 36 Roll/Case - 7010334504

Sold As: 36-Pack
SKU: 7010334504
MPN: 7010334504
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00021200414077
3M ID: 70006430287
5 Digit UPC: 41407
$4,290.25 ($119.17 / Count)
Hurry up! Current stock:

Product Description

3M™ Conformable Sound Management Film Tape 9343 is designed with a black, non-woven backing and acrylic adhesive on a polyester liner. The non-woven, microfiber backing is unique in that it provides conformability, elasticity, compressibility and durability. This tape is engineered to help reduce noise, vibration, squeaks and rattles in automotive interior applications.

Features

  • Designed to help reduce noise, friction, vibration, squeaks and rattles in automotive interior applications
  • Conformable design provides a solution for irregular-shaped parts
  • Withstands a temperature range of -30°F/-34°C to 250°F/121°C
  • Acrylic adhesive produces excellent bond strength
  • Non-woven, microfiber backing offers conformability, elasticity, compressibility and durability
  • Durable, abrasion-resistant backing maintains a long wear life, is die-cuttable and passes FMVSS 302
Spec Sheet



Downloads

Specifications

Shelf Life365
Country of OriginUnited States
Primary LinerPaper
ApplicationExterior Side Panel Bonding
Tensile Strength (Metric) UOMN/100mm
Adhesion Strength (Metric)30.0
Maximum Operating Temperature (Fahrenheit)250.0
Overall Width (Metric)25.4
IndustriesAppliance, Automotive, General Industrial, Military and Government, Specialty Vehicles, Transportation
Units per Case UOMRoll
Total Tape Thickness without Liner (Imperial) UOMmil
Overall Width (Metric) UOMmm
Adhesive TypeAcrylic
Tensile Strength (Imperial)5.0
Total Tape Thickness without Liner (Metric)0.15
Adhesion Strength (Imperial)27.0
Maximum Operating Temperature (Celsius)121.0
Minimum Operating Temperature (Fahrenheit)-30.0
Tensile Strength (Metric)8.8
Maximum Operating Temperature (Fahrenheit) UOMDegree
Overall Thickness (Imperial)19.5
Overall Length (Imperial) UOMyd
Total Tape Thickness without Liner (Metric) UOMmm
Backing MaterialNon-woven
Product FormRoll
Number of Adhesive SidesSingle-sided
Shelf Life in Months (From Date of Manufacture) UOMMonths
Total Tape Thickness without Liner (Imperial)5.9
Units per Case1.0
Overall Length (Imperial)36.0
Overall Width (Imperial)1.0
Elongation at Break400%
Adhesion Strength (Metric) UOMN/100mm
Tensile Strength (Imperial) UOMlb/in
Product TypeTape
Overall Width (Imperial) UOMin
Product ColorBlack
Backing (Carrier) MaterialNon-woven
Overall Thickness (Imperial) UOMmil
Maximum Operating Temperature (Celsius) UOMDegree
Minimum Operating Temperature (Fahrenheit) UOMDegree
Overall Length (Metric) UOMm
Shelf Life in Months (From Date of Manufacture)12.0
Overall Length (Metric)32.91
