3M Products & Supplies

3M™ Double Coated Tape 9009, Clear, 4 1/4 in x 360 yd, 2.1 mil, Roll - 7010535601

Sold As: 12-Pack
SKU: 7010535601
MPN: 7010535601
Made to Order: For a lead time estimate, please send your request to [email protected]
3M ID: CY998783617
5 Digit UPC: #VALUE!
$8,217.63 ($684.80 / Count)
Hurry up! Current stock:

Product Description

3M™ Double Coated Tape 9009 is .8 mils of 300 high strength acrylic adhesive, .5 mil polyester carrier, .8 mils of 300 high strength acrylic adhesive on a 3.2 mil 55 lb densified kraft paper liner

Features

  • 1.9 mil double coated tape with a PET polyester carrier on a 55 lb densified kraft paper liner DK
  • Good for joining and bonding in electronics and general industrial applications. Foam and gasket attachment
  • Thin double coat for applications where thickness is critical
  • High adhesion to a wide variety of materials such as HSE LSE and metals. Good temperature resistance and good UV resistance. Good peel strength
Spec Sheet



Downloads

Specifications

Shelf Life730
Country of OriginUnited States
Product ColorTransparent
Face Side Adhesive TypeHigh Strength Acrylic Adhesive 300
Overall Width (Imperial)4.25
Core Size (Metric)76.2
Face Side Adhesive Thickness (Metric) UOMmm
Overall Length (Imperial)1080.0
Face Side Adhesive Thickness (Imperial) UOMmil
Face Side Adhesive Thickness (Metric)0.02
Carrier Thickness (Metric)0.013
Core Size (Metric) UOMmm
Primary Liner ColorWhite
Overall Length (Metric)329.18
Carrier Thickness (Metric) UOMmm
Maximum Operating Temperature (Fahrenheit) UOMDegree
Face Side Adhesive Thickness (Imperial)0.8
Overall Width (Metric)108.0
Backing (Carrier) Thickness (Metric) UOMmm
Total Tape Thickness without Liner (Metric) UOMmm
Core Size (Imperial) UOMin
Minimum Operating Temperature (Fahrenheit)-40.0
Backing (Carrier) Thickness (Imperial) UOMmil
Total Tape Thickness without Liner (Imperial) UOMmil
Backing (Carrier) Thickness (Imperial)0.5
Total Tape Thickness without Liner (Imperial)2.1
Backing (Carrier) Thickness (Metric)0.013
Overall Width (Metric) UOMmm
Primary Liner Thickness (Imperial)3.2
Overall Width (Imperial) UOMin
Maximum Operating Temperature (Fahrenheit)250.0
Back Side Adhesive Thickness (Imperial)0.8
Primary Liner55# Densified Kraft Paper (DK)
Back Side Adhesive Thickness (Imperial) UOMmil
Carrier Thickness0.5
Primary Liner Thickness (Metric)0.08
Total Tape Thickness without Liner (Metric)0.05
Overall Length (Imperial) UOMft
Carrier Thickness UOMmil
Primary Liner Thickness (Metric) UOMmm
Minimum Operating Temperature (Fahrenheit) UOMDegree
Back Side Adhesive Thickness (Metric) UOMmm
Overall Length (Metric) UOMm
Tape TypeDouble Coated
Core Size (Imperial)3.0
Primary Liner Thickness (Imperial) UOMmil
