3M Products & Supplies

3M™ Double Coated Tape 9495LE, Clear, 1.5 in x 360 yd, 6.7 mil, Roll - 7010535602

Sold As: 36-Pack
SKU: 7010535602
MPN: 7010535602
Made to Order: For a lead time estimate, please send your request to [email protected]
3M ID: CY998783625
5 Digit UPC: #VALUE!
$11,106.93 ($308.53 / Count)
Hurry up! Current stock:

Product Description

3M™ Double Coated Tape 9495LE provides high bond strength to most surfaces, including many low surface energy plastics such as polypropylene and powder coated paints. The acrylic adhesive also provides excellent adhesion to surfaces contaminated lightly with oil typically used with machine parts.

Features

  • Film carrier adding dimensional stability to foams and other substrates
  • Film carrier makes for easy handling during slitting and die-cutting
  • The bond strength of 3M™ Laminating Adhesive 300LSE increases as a function of time and temperature, and has very high initial adhesion
  • High bonding strength to LSE plastics
  • Adds dimensional stability to foams and other substrates and also makes it easier to handle the tape during slitting and die-cutting
  • 3M™ Double Coated Tape 9495LE features a single liner for ease in selective die cutting
Spec Sheet



Downloads

Specifications

Shelf Life730
Country of OriginUnited States
Overall Length (Imperial)360.0
Overall Width (Metric)38.1
Back Side Adhesive Thickness (Metric) UOMmm
Primary Liner ColorTan
Primary Liner Thickness (Imperial) UOMmil
Primary Liner Thickness (Imperial)4.2
Adhesive TypeLow Surface Energy Acrylic Adhesive 300LSE
Backing (Carrier) MaterialPET
Backing (Carrier) Thickness (Imperial) UOMmil
Total Tape Thickness without Liner (Imperial)6.7
Overall Width (Imperial)1.5
Backing (Carrier) Thickness (Imperial)0.5
Overall Length (Metric) UOMm
Total Tape Thickness without Liner (Metric) UOMmm
Product ColorTransparent
Face Side Adhesive Thickness (Imperial)2.8
Product CategoryAdhesive Transfer Tapes & Double Coated Tapes
Backing (Carrier) Thickness (Metric)0.013
Overall Length (Imperial) UOMyd
Back Side Adhesive Thickness (Imperial) UOMmil
IndustriesElectronics, General Industrial
Primary Liner58# Polycoated Kraft Paper (PCK)
Overall Width (Metric) UOMmm
Backing (Carrier) Thickness (Metric) UOMmm
Primary Liner Thickness (Metric)0.11
Face Side Adhesive Thickness (Imperial) UOMmil
Overall Width (Imperial) UOMin
Back Side Adhesive Thickness (Imperial)3.4
Total Tape Thickness without Liner (Metric)0.17
Total Tape Thickness without Liner (Imperial) UOMmil
Face Side Adhesive Thickness (Metric)0.071
Face Side Adhesive Thickness (Metric) UOMmm
Overall Length (Metric)329.18
Back Side Adhesive Thickness (Metric)0.086
Primary Liner Thickness (Metric) UOMmm
