3M Products & Supplies

3M™ Double Coated Tape 9495LE, Clear, 54 in x 60 yd, 6.7 mil, Roll - 7010535840

SKU: 7010535840
MPN: 7010535840
Made to Order: For a lead time estimate, please send your request to [email protected]
3M ID: CY998786016
5 Digit UPC: #VALUE!
$1,851.15 each
Hurry up! Current stock:

Product Description

3M™ Double Coated Tape 9495LE provides high bond strength to most surfaces, including many low surface energy plastics such as polypropylene and powder coated paints. The acrylic adhesive also provides excellent adhesion to surfaces contaminated lightly with oil typically used with machine parts.

Features

  • Film carrier adding dimensional stability to foams and other substrates
  • High bonding strength to LSE plastics
  • Adds dimensional stability to foams and other substrates and also makes it easier to handle the tape during slitting and die-cutting
  • Film carrier makes for easy handling during slitting and die-cutting
  • The bond strength of 3M™ Laminating Adhesive 300LSE increases as a function of time and temperature, and has very high initial adhesion
  • 3M™ Double Coated Tape 9495LE features a single liner for ease in selective die cutting
Spec Sheet



Downloads

Specifications

Shelf Life730
Country of OriginUnited States
Back Side Adhesive Thickness (Imperial) UOMmil
Overall Width (Imperial)54.0
Backing (Carrier) Thickness (Metric) UOMmm
Backing (Carrier) Thickness (Imperial) UOMmil
Total Tape Thickness without Liner (Imperial) UOMmil
Primary Liner Thickness (Imperial)4.2
Face Side Adhesive Thickness (Metric) UOMmm
Back Side Adhesive Thickness (Metric) UOMmm
Product ColorTransparent
Overall Width (Metric)1371.6
Primary Liner Thickness (Imperial) UOMmil
Backing (Carrier) Thickness (Metric)0.013
Total Tape Thickness without Liner (Metric) UOMmm
IndustriesElectronics, General Industrial
Back Side Adhesive Thickness (Metric)0.086
Total Tape Thickness without Liner (Metric)0.17
Overall Width (Imperial) UOMin
Overall Length (Metric)54.86
Face Side Adhesive Thickness (Metric)0.071
Backing (Carrier) MaterialPET
Adhesive TypeLow Surface Energy Acrylic Adhesive 300LSE
Overall Width (Metric) UOMmm
Face Side Adhesive Thickness (Imperial) UOMmil
Overall Length (Imperial) UOMyd
Face Side Adhesive Thickness (Imperial)2.8
Primary Liner ColorTan
Product CategoryAdhesive Transfer Tapes & Double Coated Tapes
Primary Liner Thickness (Metric) UOMmm
Overall Length (Imperial)60.0
Back Side Adhesive Thickness (Imperial)3.4
Total Tape Thickness without Liner (Imperial)6.7
Overall Length (Metric) UOMm
Primary Liner Thickness (Metric)0.11
Primary Liner58# Polycoated Kraft Paper (PCK)
Backing (Carrier) Thickness (Imperial)0.5
