3M Products & Supplies

3M™ Double Coated Tape 9495LE, Clear, 54 in x 320 yd, 6.7 mil, 1 Roll/Case - 7100270013

SKU: 7100270013
MPN: 7100270013
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00068060001863
3M ID: 70007549358
5 Digit UPC: 186
$9,491.06 each
Hurry up! Current stock:

Product Description

3M™ Double Coated Tape 9495LE provides high bond strength to most surfaces, including many low surface energy plastics such as polypropylene and powder coated paints. The acrylic adhesive also provides excellent adhesion to surfaces contaminated lightly with oil typically used with machine parts.

Features

  • Film carrier adding dimensional stability to foams and other substrates
  • The bond strength of 3M™ Laminating Adhesive 300LSE increases as a function of time and temperature, and has very high initial adhesion
  • High bonding strength to LSE plastics
  • Film carrier makes for easy handling during slitting and die-cutting
  • 3M™ Double Coated Tape 9495LE features a single liner for ease in selective die cutting
  • Adds dimensional stability to foams and other substrates and also makes it easier to handle the tape during slitting and die-cutting
Spec Sheet



Downloads

Specifications

Shelf Life730
Country of OriginUnited States
Product CategoryAdhesive Transfer Tapes & Double Coated Tapes
Backing (Carrier) Thickness (Imperial)0.5
Primary Liner Thickness (Metric)0.11
Backing (Carrier) Thickness (Metric)0.013
Primary Liner Thickness (Imperial)4.2
Face Side Adhesive Thickness (Metric)0.071
Total Tape Thickness without Liner (Imperial) UOMmil
Back Side Adhesive Thickness (Metric) UOMmm
Primary Liner Thickness (Imperial) UOMmil
Back Side Adhesive Thickness (Imperial)3.4
Overall Width (Imperial) UOMin
Overall Length (Metric) UOMm
Backing (Carrier) MaterialPET
Overall Width (Metric)1371.6
Overall Length (Imperial)320.0
Back Side Adhesive Thickness (Metric)0.086
Face Side Adhesive Thickness (Imperial) UOMmil
Total Tape Thickness without Liner (Metric) UOMmm
Product ColorTransparent
Primary Liner ColorTan
Overall Width (Metric) UOMmm
Total Tape Thickness without Liner (Imperial)6.7
IndustriesElectronics, General Industrial
Backing (Carrier) Thickness (Imperial) UOMmil
Back Side Adhesive Thickness (Imperial) UOMmil
Total Tape Thickness without Liner (Metric)0.17
Primary Liner58# Polycoated Kraft Paper (PCK)
Primary Liner Thickness (Metric) UOMmm
Backing (Carrier) Thickness (Metric) UOMmm
Face Side Adhesive Thickness (Metric) UOMmm
Adhesive TypeLow Surface Energy Acrylic Adhesive 300LSE
Overall Length (Imperial) UOMyd
Overall Width (Imperial)54.0
Face Side Adhesive Thickness (Imperial)2.8
Overall Length (Metric)292.608
