3M Products & Supplies

3M™ Double Coated Tape 9495LE, Clear, 6 in x 60 yd, 6.7 mil, Roll - 7010536079

Sold As: 9-Pack
SKU: 7010536079
MPN: 7010536079
Made to Order: For a lead time estimate, please send your request to [email protected]
3M ID: CY998788418
5 Digit UPC: #VALUE!
$1,851.15 ($205.68 / Count)
Hurry up! Current stock:

Product Description

3M™ Double Coated Tape 9495LE provides high bond strength to most surfaces, including many low surface energy plastics such as polypropylene and powder coated paints. The acrylic adhesive also provides excellent adhesion to surfaces contaminated lightly with oil typically used with machine parts.

Features

  • Film carrier adding dimensional stability to foams and other substrates
  • Film carrier makes for easy handling during slitting and die-cutting
  • Adds dimensional stability to foams and other substrates and also makes it easier to handle the tape during slitting and die-cutting
  • 3M™ Double Coated Tape 9495LE features a single liner for ease in selective die cutting
  • High bonding strength to LSE plastics
  • The bond strength of 3M™ Laminating Adhesive 300LSE increases as a function of time and temperature, and has very high initial adhesion
Spec Sheet



Downloads

Specifications

Shelf Life730
Country of OriginUnited States
Total Tape Thickness without Liner (Imperial) UOMmil
Primary Liner Thickness (Metric)0.11
Back Side Adhesive Thickness (Metric) UOMmm
Overall Length (Metric) UOMm
Total Tape Thickness without Liner (Metric) UOMmm
Product CategoryAdhesive Transfer Tapes & Double Coated Tapes
Backing (Carrier) Thickness (Metric)0.013
Backing (Carrier) Thickness (Imperial)0.5
Total Tape Thickness without Liner (Imperial)6.7
Primary Liner Thickness (Imperial) UOMmil
Face Side Adhesive Thickness (Metric) UOMmm
Overall Length (Imperial)60.0
Face Side Adhesive Thickness (Imperial)2.8
Backing (Carrier) MaterialPET
Primary Liner Thickness (Metric) UOMmm
Primary Liner ColorTan
Back Side Adhesive Thickness (Imperial)3.4
Product ColorTransparent
Adhesive TypeLow Surface Energy Acrylic Adhesive 300LSE
Overall Width (Metric) UOMmm
Backing (Carrier) Thickness (Imperial) UOMmil
Overall Width (Imperial) UOMin
Back Side Adhesive Thickness (Metric)0.086
Face Side Adhesive Thickness (Metric)0.071
Primary Liner58# Polycoated Kraft Paper (PCK)
Overall Length (Metric)54.86
Primary Liner Thickness (Imperial)4.2
Overall Width (Imperial)6.0
IndustriesElectronics, General Industrial
Back Side Adhesive Thickness (Imperial) UOMmil
Backing (Carrier) Thickness (Metric) UOMmm
Face Side Adhesive Thickness (Imperial) UOMmil
Overall Width (Metric)152.4
Overall Length (Imperial) UOMyd
Total Tape Thickness without Liner (Metric)0.17
