3M Products & Supplies

3M™ Double Coated Tape 9420, Red, 1 in x 36 yd, 4 mil, 48 Roll/Case - 7010372140

Sold As: 48-Pack
SKU: 7010372140
MPN: 7010372140
For an accurate lead time please contact us
UPC: 00021200160554
3M ID: 70006062361
5 Digit UPC: 16055
$1,612.78 ($33.60 / Count)
Hurry up! Current stock:

Product Description

3M™ Double Coated Tape 9420 is a clear polyester film tape with a super aggressive, pressure sensitive acrylic adhesive and a glassine release liner. This tape uses a hand-tearable polyester film that is coated on both sides with a heavy layer of adhesive to allow for superior bonding and conformability to irregular as well as flat surfaces.

Features

  • Double sided adhesion increases dimensional stability for easy handling
  • Excellent UV resistance to withstand a variety of conditions
  • Bonds well to most substrates, including low surface energy films
  • High tack for flying splices
  • Ultra-high peel strength and excellent shear strength to withstand rigorous splicing applications
  • Conformable to bond to irregular surfaces
Spec Sheet



Downloads

Specifications

Shelf Life730
Country of OriginUnited States
Number of Adhesive SidesDouble-sided
Total Tape Thickness without Liner (Imperial) UOMmil
Face Side Adhesive Thickness (Metric)0.04
Overall Width (Metric) UOMmm
Back Side Adhesive Thickness (Imperial)1.5
Master Size Width (Metric)122.0
Carrier Thickness UOMmil
Overall Width (Metric)25.4
Maximum Operating Temperature (Fahrenheit)180.0
Overall Length (Imperial) UOMyd
Overall Thickness (Imperial)4.0
Product FormRoll
Core Size (Imperial)3.0
Overall Thickness (Imperial) UOMmil
Face Side Adhesive Thickness (Imperial) UOMmil
Face Side Adhesive TypeHigh Tack Acrylic 400
Master Size Width (Metric) UOMcm
Overall Length (Imperial)48.0
Master Size Length (Metric)98.8
Maximum Operating Temperature (Celsius)65.0
Tape TypeDouble Coated
ApplicationZero-Speed and General Splicing
Overall Length (Metric) UOMm
Primary Liner Thickness (Imperial)4.0
Master Size Length (Imperial) UOMLinear
Minimum Operating Temperature (Fahrenheit) UOMDegree
Primary Liner Thickness (Metric) UOMmm
Carrier Thickness0.09513889
Primary Liner Thickness (Imperial) UOMmil
Backing (Carrier) Thickness (Metric) UOMmm
Total Tape Thickness without Liner (Metric) UOMmm
Backing (Carrier) Thickness (Metric)0.03
Total Tape Thickness without Liner (Imperial)4.0
Maximum Operating Temperature (Fahrenheit) UOMDegree
Primary Liner60# Densified Kraft Paper
Total Tape Thickness without Liner (Metric)0.1
Primary Liner ColorTan
Backing (Carrier) MaterialPolyester
Minimum Operating Temperature (Fahrenheit)-40.0
Backing (Carrier) Thickness (Imperial) UOMmil
IndustriesPaper, Print
Back Side Adhesive Thickness (Imperial) UOMmil
Backing (Carrier) Thickness (Imperial)0.095
Overall Width (Imperial) UOMin
Carrier Thickness (Metric)0.03
Master Size Width (Imperial) UOMin
Master Size Length (Metric) UOMm
Carrier MaterialPolyester
Face Side Adhesive Thickness (Metric) UOMmm
Face Side Adhesive Thickness (Imperial)1.5
Product ColorRed
Carrier Thickness (Metric) UOMmm
Units per Case36.0
Overall Width (Imperial)1.0
Overall Length (Metric)32.91
Core Size (Metric)76.2
Core Size (Metric) UOMmm
Master Size Length (Imperial)108.0
Core Size (Imperial) UOMin
Back Side Adhesive Thickness (Metric) UOMmm
Master Size Width (Imperial)48.0
Primary Liner Thickness (Metric)0.1
