3M Products & Supplies

3M™ Double Coated Tape 9628B, Black, 1 in x 60 yd, 2 Mil, 36/Case - 7010335509

Sold As: 36-Pack
SKU: 7010335509
MPN: 7010335509
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051111919897
3M ID: 70006706264
5 Digit UPC: 91989
$774.90 ($21.52 / Count)
Hurry up! Current stock:

Product Description

2.0 mil 360 high performance quick stick acrylic adhesive double coat with a black polyester (PET) carrier on a 3.2 mil glassine paper liner

Features

  • 2 mil double coated tape on a black PET polyester carrier with a 3.2 mil glassine paper liner. Black carrier for improved die-cutting and processing.
  • Good solvent resistance and excellent moisture resistance. Adheres well to a variety of plastics such as ABS, HDPE, PP, PMMA, acrylic and polycarbonate. Ideal for electronic devices.
  • Double coated tape has exceptional adhesion properties and bonds well to high and low surface energy plastics HSE LSE such as HDPE, PP, ABS, polycarbonate, PMMA; powder coated paints. Has excellent quick stick properties.
Spec Sheet



Downloads

Specifications

Shelf Life730
Country of OriginUnited States
Overall Width (Metric) UOMmm
Face Side Adhesive Thickness (Metric)0.019
Backing (Carrier) Thickness (Imperial) UOMmil
Overall Length (Metric)54.86
Maximum Operating Temperature (Celsius)93.0
Face Side Adhesive Thickness (Metric) UOMmm
IndustriesElectronics, General Industrial
Units per Case36.0
Backing (Carrier) Thickness (Metric)0.013
Overall Width (Imperial) UOMin
Overall Length (Imperial)60.0
Backing (Carrier) MaterialPET
Overall Length (Imperial) UOMyd
Adhesive TypeQuick Bond Acrylic Adhesive 360
Minimum Operating Temperature (Celsius)-40.0
Overall Length (Metric) UOMm
Back Side Adhesive Thickness (Imperial) UOMmil
Minimum Operating Temperature (Celsius) UOMDegree
Face Side Adhesive Thickness (Imperial)0.75
Backing (Carrier) Thickness (Metric) UOMmm
Backing (Carrier) Thickness (Imperial)0.5
Product ColorBlack
Total Tape Thickness without Liner (Metric)0.1
Total Tape Thickness without Liner (Imperial) UOMmil
Back Side Adhesive Thickness (Metric)0.019
Back Side Adhesive Thickness (Metric) UOMmm
Maximum Operating Temperature (Celsius) UOMDegree
Overall Width (Metric)25.4
Product CategoryAdhesive Transfer Tapes & Double Coated Tapes
Face Side Adhesive Thickness (Imperial) UOMmil
Total Tape Thickness without Liner (Imperial)4.0
Overall Width (Imperial)1.0
Total Tape Thickness without Liner (Metric) UOMmm
Back Side Adhesive Thickness (Imperial)0.75
