3M Products & Supplies

3M™ Double Coated Tape 9628B, Black, 54 in x 60 yd, 2 mil, 1 Roll/Case - 7100001100

SKU: 7100001100
MPN: 7100001100
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051111977835
3M ID: 70006720109
5 Digit UPC: 97783
$1,162.35 each
Hurry up! Current stock:

Product Description

2.0 mil 360 high performance quick stick acrylic adhesive double coat with a black polyester (PET) carrier on a 3.2 mil glassine paper liner

Features

  • Good solvent resistance and excellent moisture resistance. Adheres well to a variety of plastics such as ABS, HDPE, PP, PMMA, acrylic and polycarbonate. Ideal for electronic devices.
  • Double coated tape has exceptional adhesion properties and bonds well to high and low surface energy plastics HSE LSE such as HDPE, PP, ABS, polycarbonate, PMMA; powder coated paints. Has excellent quick stick properties.
  • 2 mil double coated tape on a black PET polyester carrier with a 3.2 mil glassine paper liner. Black carrier for improved die-cutting and processing.
Spec Sheet



Downloads

Specifications

Shelf Life730
Country of OriginUnited States
Backing (Carrier) Thickness (Imperial) UOMmil
Overall Length (Imperial) UOMyd
Face Side Adhesive Thickness (Metric) UOMmm
Overall Width (Imperial) UOMin
Product CategoryAdhesive Transfer Tapes & Double Coated Tapes
Backing (Carrier) MaterialPET
Overall Width (Imperial)54.0
Back Side Adhesive Thickness (Metric) UOMmm
Backing (Carrier) Thickness (Imperial)0.5
Backing (Carrier) Thickness (Metric)0.013
Backing (Carrier) Thickness (Metric) UOMmm
Minimum Operating Temperature (Celsius)-40.0
Back Side Adhesive Thickness (Imperial) UOMmil
Back Side Adhesive Thickness (Metric)0.019
Back Side Adhesive Thickness (Imperial)0.75
Face Side Adhesive Thickness (Metric)0.019
Overall Width (Metric) UOMmm
Overall Length (Metric) UOMm
IndustriesElectronics, General Industrial
Overall Length (Imperial)60.0
Face Side Adhesive Thickness (Imperial)0.75
Maximum Operating Temperature (Celsius)93.0
Total Tape Thickness without Liner (Imperial)4.0
Total Tape Thickness without Liner (Imperial) UOMmil
Adhesive TypeQuick Bond Acrylic Adhesive 360
Units per Case1.0
Minimum Operating Temperature (Celsius) UOMDegree
Maximum Operating Temperature (Celsius) UOMDegree
Total Tape Thickness without Liner (Metric)0.1
Overall Length (Metric)54.86
Overall Width (Metric)1371.6
Face Side Adhesive Thickness (Imperial) UOMmil
Total Tape Thickness without Liner (Metric) UOMmm
