3M Products & Supplies

3M™ Double Coated Tape Extended Liner 476XL, Translucent, 1 in x 540 yd, 6 mil, 6 Roll/Case - 7000048730

Sold As: 6-Pack
SKU: 7000048730
MPN: 7000048730
For an accurate lead time please contact us
UPC: 00021200305979
3M ID: 70006213493
5 Digit UPC: 30597
$1,081.09 ($180.18 / Count)
Hurry up! Current stock:

Product Description

3M™ Double Coated Tape Extended Liner 476XL is a general purpose tape with a pressure sensitive adhesive mounted on a removable extended paper liner for easy liner starting and removal. It is ideal for a variety of closure applications, point-of-purchase displays and indirect food contact applications.

Features

  • Easy liner starting and removal helps keep jobs running smoothly
  • This version of the tape features 3M™ Adhesive 760 and has a 0.08 mil liner
  • Tack free tape roll edges for ease of use and reduced equipment maintenance
  • Ideal for secure closure of shipping boxes, tubes and envelopes
  • Dry edge and finger lift edge liners for added user convenience
Spec Sheet



Downloads

Specifications

Shelf Life547
Country of OriginUnited States
Backing (Carrier) Thickness (Metric)0.05
Face Side Adhesive Thickness (Metric) UOMmm
Indoor/OutdoorIndoor
Adhesive TypeSynthetic Rubber
Overall Width (Metric)25.4
Primary Liner Thickness (Metric) UOMmm
Total Tape Thickness without Liner (Metric)0.065
Total Tape Thickness without Liner (Metric) UOMmm
Face Side Adhesive Thickness (Metric)0.05
Backing (Carrier) MaterialTissue
Minimum Operating Temperature (Fahrenheit)-40.0
Backing (Carrier) Thickness (Imperial)2.0
Total Tape Thickness without Liner (Imperial) UOMmil
Overall Length (Metric)493.77
Minimum Operating Temperature (Celsius) UOMDegree
Primary Liner Thickness (Metric)0.094
Primary Liner ColorWhite
Maximum Operating Temperature (Celsius) UOMDegree
Units per Case6.0
Total Tape Thickness without Liner (Imperial)2.5
Overall Width (Imperial)1.0
Overall Length (Imperial)540.0
Backing (Carrier) Thickness (Metric) UOMmm
Maximum Operating Temperature (Celsius)49.0
ApplicationAttaching; Bonding; High Tack Adhesion; Holding; Joining; Laminating; Mounting; Splicing
Backing (Carrier) Thickness (Imperial) UOMmil
Overall Length (Metric) UOMm
Overall Width (Imperial) UOMin
Number of Adhesive SidesDouble-sided
Shelf Life UOMMonth
Overall Width (Metric) UOMmm
Maximum Operating Temperature (Fahrenheit)120.0
Face Side Adhesive Thickness (Imperial)2.0
Face Side Adhesive Thickness (Imperial) UOMmil
Primary Liner Thickness (Imperial)3.7
Product ColorTranslucent
Back Side Adhesive Thickness (Imperial) UOMmil
Back Side Adhesive Thickness (Imperial)2.0
Primary Liner62# Densified Kraft Paper
Maximum Operating Temperature (Fahrenheit) UOMDegree
Primary Liner Thickness (Imperial) UOMmil
IndustriesAppliance, Consumer Goods, Converter Solutions, Craft, Electronics, Food and Beverage, General Industrial, MRO, Packaging, Paper, Point of Purchase, Print, Signage
Minimum Operating Temperature (Celsius)-40.0
Minimum Operating Temperature (Fahrenheit) UOMDegree
Overall Length (Imperial) UOMyd
