3M Products & Supplies

3M™ Double Coated Tape Extended Liner 476XL, Translucent, 2 in x 540 yd, 6 mil, 3 Roll/Case - 7010374001

Sold As: 3-Pack
SKU: 7010374001
MPN: 7010374001
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00021200435416
3M ID: 70006282704
5 Digit UPC: 43541
$1,081.06 ($360.35 / Count)
Hurry up! Current stock:

Product Description

3M™ Double Coated Tape Extended Liner 476XL is a general purpose tape with a pressure sensitive adhesive mounted on a removable extended paper liner for easy liner starting and removal. It is ideal for a variety of closure applications, point-of-purchase displays and indirect food contact applications.

Features

  • This version of the tape features 3M™ Adhesive 760 and has a 0.08 mil liner
  • Tack free tape roll edges for ease of use and reduced equipment maintenance
  • Ideal for secure closure of shipping boxes, tubes and envelopes
  • Easy liner starting and removal helps keep jobs running smoothly
  • Dry edge and finger lift edge liners for added user convenience
Spec Sheet



Downloads

Specifications

Shelf Life547
Country of OriginUnited States
Overall Width (Imperial) UOMin
Number of Adhesive SidesDouble-sided
Primary Liner ColorWhite
Overall Width (Metric)50.8
Minimum Operating Temperature (Celsius)-40.0
Backing (Carrier) Thickness (Metric) UOMmm
Face Side Adhesive Thickness (Metric) UOMmm
Indoor/OutdoorIndoor
Primary Liner Thickness (Imperial)3.7
Total Tape Thickness without Liner (Metric)0.065
Maximum Operating Temperature (Fahrenheit)120.0
Back Side Adhesive Thickness (Imperial) UOMmil
Overall Width (Imperial)2.0
Overall Width (Metric) UOMmm
Face Side Adhesive Thickness (Imperial) UOMmil
Total Tape Thickness without Liner (Metric) UOMmm
Face Side Adhesive Thickness (Imperial)2.0
Units per Case3.0
Overall Length (Imperial)540.0
Backing (Carrier) Thickness (Imperial) UOMmil
Product ColorTranslucent
Backing (Carrier) Thickness (Metric)0.05
Minimum Operating Temperature (Celsius) UOMDegree
Maximum Operating Temperature (Celsius)49.0
Maximum Operating Temperature (Celsius) UOMDegree
Maximum Operating Temperature (Fahrenheit) UOMDegree
Primary Liner62# Densified Kraft Paper
IndustriesAppliance, Consumer Goods, Converter Solutions, Craft, Electronics, Food and Beverage, General Industrial, MRO, Packaging, Paper, Point of Purchase, Print, Signage
Overall Length (Imperial) UOMyd
Overall Length (Metric) UOMm
Primary Liner Thickness (Metric) UOMmm
Back Side Adhesive Thickness (Imperial)2.0
Adhesive TypeSynthetic Rubber
Minimum Operating Temperature (Fahrenheit)-40.0
Shelf Life UOMMonth
ApplicationAttaching; Bonding; High Tack Adhesion; Holding; Joining; Laminating; Mounting; Splicing
Primary Liner Thickness (Imperial) UOMmil
Primary Liner Thickness (Metric)0.094
Backing (Carrier) Thickness (Imperial)2.0
Backing (Carrier) MaterialTissue
Total Tape Thickness without Liner (Imperial) UOMmil
Total Tape Thickness without Liner (Imperial)2.5
Face Side Adhesive Thickness (Metric)0.05
Overall Length (Metric)493.77
Minimum Operating Temperature (Fahrenheit) UOMDegree
